4
Fig. 5 Remote Control Unit
D SLEEP button
E MASTER CONTROL button
F SET TEMP. button (
/ )
G Signal Transmitter
H OFF TIMER button
I ON TIMER button
J SET TIMER button
K CANCEL TIMER button
L FAN CONTROL button
M START/STOP button
N AIR FLOW DIRECTION button
O SWING LOUVER button
P ACL button
Q TEST RUN button
● This button is used when installing the
conditioner, and should not be used un-
der normal conditions, as it will cause the
air conditioner’s thermostat function to op-
erate incorrectly.
● If this button is pressed during normal op-
eration, the unit will switch to test opera-
tion mode, and the Indoor Unit’s OPERA-
TION Indicator Lamp and TIMER Indicator
Lamp will begin to flash simultaneously.
● To stop the test operation mode, press the
START/STOP button to stop the air condi-
tioner.
R Remote Control Unit Display (Fig. 6)
S Transmit Indicator
T Operating Mode Display
U Timer Mode Display
OFF TIMER Mark:
ON TIMER Mark:
SLEEP TIMER Mark:
V Fan Speed Display
W Temperature and time display
It displays the temperature setting. However,
when making the Timer setting, it will display
the Timer time. (The temperature setting will
reappear after finishing the timer setting)
Fig. 1 Indoor Unit
1 Operating Control Panel (Fig. 2)
2 MANUAL AUTO button
3 Remote Control Signal Receiver
4 Indicator Lamps (Fig. 3)
5 OPERATION Indicator Lamp (red)
6 TIMER Indicator Lamp (green)
●
If the TIMER indicator lamp flashes when
the timer is operating, it indicates that a
fault has occurred with the timer setting
(See Page 15 Auto Restart).
7 SWING Indicator Lamp (orange)
8 Intake Grille (Fig. 4)
9 Air Filter
0 Air Flow Direction Louver
A Right-Left Louver
(behind Air Flow Direction Louver)
B Drain Hose
C Air Cleaning Filter (optional)
9375339012_OM_en.p65 21/12/05, 9:594
