WALL MOUNTED TYPE ASU9-12RLF1 WALL MOUNTED TYPE ASU9-12RLF1
CAPACITY TABLE6.
COOLING CAPACITY6-1.
MODEL

: ASU9RLF1
AFR : Air ow rate (CFM)
TC : Total capacity (kBTU)
SHC : Sensible Heat capacity (kBTU)
IP : Input Power (kW)
AFR : Air ow rate (m
3
/min)
TC : Total capacity (kW)
SHC : Sensible Heat capacity (kW)
IP : Input Power (kW)
MODEL

: ASU12RLF1
AFR : Air ow rate (CFM)
TC : Total capacity (kBTU)
SHC : Sensible Heat capacity (kBTU)
IP : Input Power (kW)
AFR : Air ow rate (m
3
/min)
TC : Total capacity (kW)
SHC : Sensible Heat capacity (kW)
IP : Input Power (kW)
AFR 441
Indoor temperature
°FDB 64 70 75 80 85 90
°FWB 54 60 63 67 71 73
Outdoor temperature
°FDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
59 6.41 4.83 0.22 7.14 4.86 0.23 7.87 5.30 0.23 8.11 5.72 0.23 8.60 5.70 0.23 9.08 6.07 0.24
67 8.53 5.30 0.44 9.51 5.33 0.45 10.48 5.81 0.46 10.80 6.28 0.46 11.45 6.25 0.46 12.10 6.66 0.47
77 8.03 5.30 0.51 8.95 5.34 0.52 9.86 5.82 0.52 10.17 6.29 0.53 10.78 6.26 0.53 11.39 6.67 0.54
87 7.53 5.11 0.57 8.38 5.14 0.58 9.24 5.60 0.59 9.53 6.05 0.59 10.10 6.03 0.60 10.67 6.42 0.61
95 7.11 4.98 0.63 7.92 5.01 0.64 8.73 5.46 0.65 9.00 5.90 0.65 9.54 5.88 0.66 10.08 6.26 0.66
104 5.91 4.64 0.51 6.59 4.67 0.52 7.26 5.09 0.53 7.48 5.50 0.53 7.93 5.48 0.54 8.38 5.83 0.54
115 4.18 3.28 0.39 4.66 3.30 0.39 5.13 3.60 0.40 5.29 3.89 0.40 5.61 3.87 0.41 5.93 4.13 0.41
AFR 12.5
Indoor temperature
°CDB 17.8 21.1 23.9 26.7 29.4 32.2
°CWB 12.2 15.6 17.7 19.4 21.7 22.8
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
15.0 1.88 1.42 0.22 2.09 1.42 0.23 2.31 1.55 0.23 2.38 1.68 0.23 2.52 1.67 0.23 2.66 1.78 0.24
19.4 2.50 1.55 0.44 2.79 1.56 0.45 3.07 1.70 0.46 3.17 1.84 0.46 3.36 1.83 0.46 3.55 1.95 0.47
25.0 2.35 1.55 0.51 2.62 1.56 0.52 2.89 1.71 0.52 2.98 1.84 0.53 3.16 1.83 0.53 3.34 1.95 0.54
30.6 2.21 1.50 0.57 2.46 1.51 0.58 2.71 1.64 0.59 2.79 1.77 0.59 2.96 1.77 0.60 3.13 1.88 0.61
35.0 2.08 1.46 0.63 2.32 1.47 0.64 2.56 1.60 0.65 2.64 1.73 0.65 2.80 1.72 0.66 2.95 1.83 0.66
40.0 1.73 1.36 0.51 1.93 1.37 0.52 2.13 1.49 0.53 2.19 1.61 0.53 2.33 1.60 0.54 2.46 1.71 0.54
46.1 1.23 0.96 0.39 1.37 0.97 0.39 1.50 1.06 0.40 1.55 1.14 0.40 1.64 1.13 0.41 1.74 1.21 0.41
AFR 441
Indoor temperature
°FDB 64 70 75 80 85 90
°FWB 54 60 63 67 71 73
Outdoor temperature
°FDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
59 8.3 6.34 0.40 9.3 6.38 0.41 10.2 6.96 0.42 10.5 7.51 0.42 11.1 7.48 0.42 11.8 7.97 0.43
67 11.4 7.47 0.65 12.7 7.52 0.66 14.0 8.20 0.67 14.5 8.85 0.68 15.3 8.82 0.68 16.2 9.39 0.69
77 10.8 7.14 0.75 12.0 7.18 0.76 13.3 7.83 0.77 13.7 8.46 0.77 14.5 8.42 0.78 15.3 8.97 0.79
87 10.1 6.99 0.85 11.2 7.03 0.86 12.4 7.67 0.87 12.8 8.28 0.88 13.5 8.25 0.88 14.3 8.78 0.89
95 9.5 6.67 0.93 10.6 6.71 0.94 11.6 7.32 0.96 12.0 7.91 0.96 12.7 7.87 0.97 13.4 8.39 0.98
104 8.0 6.35 0.87 9.0 6.39 0.89 9.9 6.97 0.90 10.2 7.52 0.91 10.8 7.49 0.92 11.4 7.98 0.92
115 5.6 5.15 0.69 6.3 5.18 0.70 6.9 5.65 0.71 7.2 6.10 0.71 7.6 6.07 0.72 8.0 6.47 0.73
AFR 12.5
Indoor temperature
°CDB 17.8 21.1 23.9 26.7 29.4 32.2
°CWB 12.2 15.6 17.7 19.4 21.7 22.8
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
15.0 2.43 1.86 0.40 2.71 1.87 0.41 2.99 2.04 0.42 3.08 2.20 0.42 3.27 2.19 0.42 3.45 2.34 0.43
19.4 3.35 2.19 0.65 3.73 2.20 0.66 4.12 2.40 0.67 4.24 2.59 0.68 4.50 2.58 0.68 4.75 2.75 0.69
25.0 3.17 2.09 0.75 3.53 2.10 0.76 3.89 2.30 0.77 4.01 2.48 0.77 4.25 2.47 0.78 4.49 2.63 0.79
30.6 2.96 2.05 0.85 3.30 2.06 0.86 3.63 2.25 0.87 3.75 2.43 0.88 3.97 2.42 0.88 4.19 2.57 0.89
35.0 2.78 1.96 0.93 3.10 1.97 0.94 3.41 2.15 0.96 3.52 2.32 0.96 3.73 2.31 0.97 3.94 2.46 0.98
40.0 2.36 1.86 0.87 2.63 1.87 0.89 2.90 2.04 0.90 2.99 2.20 0.91 3.16 2.20 0.92 3.34 2.34 0.92
46.1 1.66 1.51 0.69 1.84 1.52 0.70 2.03 1.65 0.71 2.10 1.79 0.71 2.22 1.78 0.72 2.35 1.90 0.73
