Fujitsu ASU12RLF1

- (01 - 02) -
WALL MOUNTED TYPE ASU9-12RLF1 WALL MOUNTED TYPE ASU9-12RLF1
Powerful operation
z
20 minutes continuous operation by maximum airow and maximum compressor speed is
possible. Rapid cooling and heating makes the room comfortable quickly.
Powerful
Setting temp.
Normal mode
Time
Temperature
Economy operation
z
Example : Cooling operation
• Economy operation is energy saving, as the set temperature of indoor unit is shifted by 2°F (1°C)
and the maximum electric value of the outdoor unit is suppressed.
Temp.
Economy operation
Shift
setting
temp
Control maximum current
Normal operation
Time
Set temperature
Low outdoor air temperature correspondence
z
Corresponds to cooling operation at 14°F (-10°C) outdoor air temperature
Corresponds to heating operation at 5°F (-15°C) outdoor air temperature
Cooling Heating
14 to 115°F
(-10 to 46°C)
5 to 75 °F
(-15 to 24°C)
