Multiple outdoor unit installation
• When the upper space is open:
Unit: in (mm)
When there are obstacles at the rear only. When there are obstacles at the front only.
When there are obstacles at the front and
rear.
8 (200) or more
40 (1,000) or more
• When there is an obstruction in the upper space:
Unit: in (mm)
When there are obstacles at the rear and above.
60 (1,500)
or more
8 (200) or more
Max. 11 (300)
- 43 -
3-1. Models: AOU9RLS3H, AOU12RLS3H, and AOU15RLS3H 3. Installation space
OUTDOOR UNIT
AOU9-15RLS3H
OUTDOOR UNIT
AOU9-15RLS3H
