Fujitsu ASU15RLS2 Service Manual

SPECIFICATIONS
TYPE Cool & heat inverter
INDOOR UNIT
ASU15RLS2
OUTDOOR UNIT
AOU15RLS2H
COOLING CAPACITY
HEATING CAPACITY
POWER SOURCE
FREQUENCY
RUNNING
CURRENT
MAXIMUM
CURRENT
INPUT WATTS
E.E.R.
Cooling
COP
Heating
Cooling
Heating
Cooling
Heating
Cooling
Heating
Cooling
Heating
MOISTURE REMOVAL
AIR
CIRCULATION
HIGH
FAN MOTOR
POWER SOURCE
208/230 V
High
INDOOR UNIT
Cooling
Medium
Low
Quiet
High
INDOOR UNIT
Heating
Medium
Low
Quiet
OUTDOOR UNIT Heating
OUTDOOR UNIT Cooling
14,500 Btu/h
18,000 Btu/h
208/230 V
60 Hz
5.5 A
6.1 A
1.21 kW
1.35 kW
12.0 Btu/Wh
13.3 Btu/Wh
4.4 Pts/h, 2.1 L/h
529 CFM, 900 m
3
/h
559 CFM, 950 m
3
/h
9.9 A
14.9 A
1,440 r.p.m.
1,220 r.p.m.
980 r.p.m.
740 r.p.m.
1,510 r.p.m.
1,220 r.p.m.
1,030 r.p.m.
790 r.p.m.
780 r.p.m.
870 r.p.m.
ELECTRICAL DATA
2012.12.25 1
High
Medium
Low
Quiet
INDOOR UNIT
Cooling
High
Medium
Low
Quiet
INDOOR UNIT
Heating
OUTDOOR UNIT Heating
NOISE LEVEL
OUTDOOR UNIT Cooling
45 dB
40 dB
33 dB
25 dB
45 dB
40 dB
34 dB
27 dB
51 dB
51 dB
COMPRESSOR TYPE
Hermetic type,
4 pole, 3 phase,
DC inverter motor,
Rotary
DISCRIMINATION
PRECHARGED REFRIGERANT
REFRIGERANT TYPE R410A
WEIGHT (with oil)
COMPRESSOR AND REFRIGERANT
Pipe length
49 ft., 15 m
FULL CHARGE
66 ft., 20 m
MAXIMUM PIPING HEIGHT 49 ft., 15 m
ADDITIONAL CHARGE
0.22 oz/ft, 20 g/m
808-213-80
2 lb. 12 oz., 1,250 g
2 lb. 12 oz., 1,250 g
21 lb. 6 oz., 9.7 kg
3 lb., 1,350 g
WEIGHT
INDOOR UNIT
Net / Shipping
Net / Shipping
21 lb. / 27 lb.
9.5 kg / 12.0 kg
OUTDOOR UNIT
INDOOR UNIT
H x W x D
H x W x D
11-3/32 x 34-1/4 x 7-9/32 in.
282 x 870 x 185 mm
OUTDOOR UNIT
86 lb. / 95 lb.
40 kg / 43 kg
DIMENSIONS
24-13/32 x 31-3/32 x 11-13/32 in.
620 x 790 x 290 mm

Fujitsu ASU15RLS2 Specifications

General

Brand	Fujitsu
Model	ASU15RLS2
Category	Air Conditioner
Language	English
