Fujitsu ASU15RLS3 Service Manual

P ARTS
INDOOR UNIT
2015.01.09 11
6
9
10
8
Intake Grille with logotype 9333052083
7 Front Panel Sub Assy 9320459017
Bracket Panel
4
Wire Cover 9318786026
Wire shield
Electric Filter Holder 9332911008
5 Air Clean Filter Assy 9317250009
1
Remote Control 9320360047
2
3
Remote Control Holder 9318912005
9318861013
Ref. Description Part number
Air Filter 9380997009
Louver 9318849028
11 Diffuser Assy 9319232096
9
5
4
3
6
8
1
2
7
10
11
