OUTDOOR UNIT
2014.12.15
19
42 Compressor Assy 9318334005
44 3-way Valve Sub Assy 9317109062
47 Pulse Motor Valve Assy 9315587046
46 Solenoid 9970110023
41
Condenser Total Assy (RLS3)
9317089128
41
Condenser Total Assy (RLS3H)
9317089104
48 Expansion Valve Coil 9970095030
45 4-way Valve Assy 9318457018
43 2-way Valve Sub Assy 9317345019
Ref. Description Part number
42
41
46
45
47
48
44
43
49
Heater holder A
Heater holder B
49 Heater Unit Assy (RLS3H) 9900616014
To Next Page
