MULTI TYPE 3-4ROOMS TYPE MULTI TYPE 3-4ROOMS TYPE
6. CAPACITY TABLE
6-1. WALL MOUNTED COMBINATIONS
COOLING
HEATING
MODEL : ASU9R + ASU9R + ASU9R / AOU36R
AFR
(°FDB) TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
32
22.34 18.66 0.99 25.20 18.77 1.01 26.62 20.57 1.02 28.52 21.52 1.03 30.43 22.22 1.04 31.38 24.63 1.05
41
21.52 17.98 1.18 24.28 18.09 1.20 25.64 19.82 1.21 27.47 20.73 1.23 29.31 21.41 1.24 30.23 23.73 1.25
50
20.38 17.48 1.34 22.98 17.58 1.37 24.28 19.27 1.38 26.01 20.16 1.39 27.75 20.82 1.41 28.62 23.07 1.42
59
21.74 18.07 1.44 24.52 18.18 1.46 25.90 19.92 1.47 27.75 20.84 1.49 29.61 21.52 1.51 30.53 23.86 1.52
67
26.31 20.13 1.80 29.67 20.25 1.83 31.35 22.19 1.85 33.58 23.21 1.87 35.83 23.97 1.89 36.95 26.57 1.90
77
24.39 19.25 2.05 27.51 19.37 2.09 29.06 21.22 2.10 31.14 22.21 2.13 33.22 22.93 2.15 34.26 25.42 2.16
87
25.24 20.10 2.81 28.47 20.22 2.86 30.07 22.16 2.88 32.22 23.18 2.91 34.37 23.94 2.95 35.44 26.54 2.96
95
25.86 19.92 3.61 29.16 20.04 3.67 30.81 21.96 3.70 33.00 22.97 3.74 35.21 23.72 3.78 36.31 26.30 3.81
104
21.08 17.78 3.14 23.77 17.89 3.19 25.11 19.60 3.22 26.90 20.51 3.26 28.70 21.18 3.29 29.60 23.47 3.31
115
14.25 14.88 2.27 16.07 14.97 2.31 16.98 16.40 2.33 18.19 17.16 2.36 19.40 17.72 2.39 20.01 19.65 2.40
AFR : Air flow rate (CFM) TC : Total capacity (kBTU) SHC : Sensible Heat capacity (kBTU) PI : Power Input (kW)
Outdoor temperature
312 + 312 + 312
90°FDB
67°FWB
71°FWB
85°FDB
75°FDB
64°FDB
73°FWB
70°FDB
Indoor temperature
54°FWB
60°FWB
63°FWB
80°FDB
AFR
(°CDB) TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
6.54 5.46 0.99 7.38 5.50 1.01 7.80 6.02 1.02 8.35 6.30 1.03 8.91 6.51 1.04 9.19 7.21 1.05
6.30 5.27 1.18 7.11 5.30 1.20 7.51 5.80 1.21 8.05 6.07 1.23 8.59 6.27 1.24 8.85 6.95 1.25
5.97 5.12 1.34 6.73 5.15 1.37 7.11 5.64 1.38 7.62 5.90 1.39 8.13 6.10 1.41 8.38 6.76 1.42
6.37 5.29 1.44 7.18 5.33 1.46 7.59 5.83 1.47 8.13 6.10 1.49 8.67 6.30 1.51 8.94 6.99 1.52
7.71 5.90 1.80 8.69 5.93 1.83 9.18 6.50 1.85 9.84 6.80 1.87 10.49 7.02 1.89 10.82 7.78 1.90
7.14 5.64 2.05 8.06 5.67 2.09 8.51 6.22 2.10 9.12 6.50 2.13 9.73 6.72 2.15 10.03 7.45 2.16
7.39 5.89 2.81 8.34 5.92 2.86 8.81 6.49 2.88 9.44 6.79 2.91 10.07 7.01 2.95 10.38 7.77 2.96
7.57 5.83 3.61 8.54 5.87 3.67 9.02 6.43 3.70 9.70 6.75 3.74 10.31 6.95 3.78 10.64 7.70 3.81
6.17 5.21 3.14 6.96 5.24 3.19 7.35 5.74 3.22 7.88 6.01 3.26 8.41 6.20 3.29 8.67 6.88 3.31
4.17 4.36 2.27 4.71 4.39 2.31 4.97 4.80 2.33 5.33 5.03 2.36 5.68 5.19 2.39 5.86 5.75 2.40
AFR : Air flow rate (m
3
/min) TC : Total capacity (kW) SHC : Sensible Heat capacity (kW) PI : Power Input (kW)
Outdoor temperature
17.2°CWB
19.4°CWB
12.2°CWB
15.6°CWB
21.7°CWB
8.8 + 8.8 + 8.8
22.8°CWB
Indoor temperature
17.8°CDB
21.1°CDB
23.9°CDB
26.7°CDB
29.4°CDB
32.2°CDB
0.00
5.00
10.00
15.00
19.44
25.00
30.56
35.00
40.00
46.11
AFR
(°FDB) (°FWB) TC PI TC PI TC PI TC PI TC PI
14 12
27.57 2.96 26.67 3.05 25.78 3.13 24.88 3.22 24.34 3.27
23 19
31.75 3.11 30.73 3.20 29.69 3.29 28.66 3.38 28.04 3.44
32 28
38.03 3.28 36.80 3.38 35.56 3.48 34.33 3.57 33.58 3.63
41 37
40.84 3.47 39.52 3.57 38.19 3.67 36.86 3.78 36.07 3.84
47 43
42.99 3.59 41.60 3.70 40.20 3.80 38.80 3.91 37.97 3.97
50 47
45.79 3.67 44.30 3.78 42.82 3.89 41.33 4.00 40.43 4.06
59 50
43.30 3.08 41.90 3.17 40.49 3.26 39.08 3.35 38.24 3.40
68 59
41.29 2.59 39.95 2.66 38.61 2.74 37.27 2.81 36.46 2.86
75 65
44.36 2.59 42.93 2.66 41.48 2.74 40.04 2.81 39.18 2.86
AFR : Air flow rate(CFM) TC : Total capacity (kBTU) PI : Power Input (kW)
Outdoor temperature
Indoor temperature
60°FDB
65°FDB
70°FDB
75°FDB
78°FDB
312 + 312 + 312
This table is created using the maximum capacity.
AFR
(°CDB) (°CWB) TC PI TC PI TC PI TC PI TC PI
8.07 2.96 7.81 3.05 7.55 3.13 7.29 3.22 7.13 3.27
9.30 3.11 9.00 3.20 8.70 3.29 8.39 3.38 8.21 3.44
11.14 3.28 10.78 3.38 10.42 3.48 10.05 3.57 9.84 3.63
11.96 3.47 11.57 3.57 11.19 3.67 10.80 3.78 10.56 3.84
12.59 3.59 12.18 3.70 11.80 3.80 11.37 3.91 11.12 3.97
13.41 3.67 12.98 3.78 12.54 3.89 12.10 4.00 11.84 4.06
12.68 3.08 12.27 3.17 11.86 3.26 11.45 3.35 11.20 3.40
12.09 2.59 11.70 2.66 11.31 2.74 10.92 2.81 10.68 2.86
12.99 2.59 12.57 2.66 12.15 2.74 11.73 2.81 11.47 2.86
AFR : Air flow rate (m
3
/min) TC : Total capacity (kW) PI : Power Input (kW)
8.8 + 8.8 + 8.8
Outdoor temperature
Indoor temperature
15.6°CDB
18.3°CDB
21.1°CDB
23.9°CDB
25.6°CDB
-10.00 -11.11
-5.00 -7.22
0.00 -2.22
5.00 2.78
8.33 6.11
10.00 8.33
15.00 10.00
20.00 15.00
23.89 18.33
