Fujitsu ASUH24LPAS User Manual

Indoor unit connect-
ing capacity
Outdoor temperature
Indoor temperature
64 °FDB 70 °FDB 75 °FDB 80 °FDB 85 °FDB 90 °FDB
54 °FWB 60 °FWB 63 °FWB 67 °FWB 71 °FWB 73 °FWB
kBtu/h °FDB TC IP TC IP TC IP TC IP TC IP TC IP
34
14
28.4 1.11 32.1 1.13 33.9 1.14 36.3 1.15 38.8 1.17 40.0 1.17
23 28.4 1.10 32.1 1.12 33.9 1.13 36.3 1.15 38.8 1.16 40.0 1.17
32 28.4 1.10 32.1 1.12 33.9 1.13 36.3 1.14 38.8 1.15 40.0 1.16
41 28.4 1.22 32.1 1.25 33.9 1.26 36.3 1.27 38.8 1.28 40.0 1.29
50 28.4 1.35 32.1 1.37 33.9 1.39 36.3 1.40 38.8 1.42 40.0 1.42
59 28.4 1.86 32.1 1.89 33.9 1.91 36.3 1.93 38.8 1.95 40.0 1.96
67 28.4 2.37 32.1 2.41 33.9 2.43 36.3 2.45 38.8 2.48 40.0 2.50
77 28.4 2.61 32.1 2.65 33.9 2.67 36.3 2.70 38.8 2.74 40.0 2.75
87 28.4 2.85 32.1 2.90 33.9 2.92 36.3 2.95 38.8 2.99 40.0 3.00
95 28.4 3.04 32.1 3.09 33.9 3.12 36.3 3.15 38.8 3.19 40.0 3.21
104 24.7 2.82 28.0 2.87 29.5 2.90 31.5 2.93 33.7 2.96 34.8 2.98
115 21.0 2.61 23.8 2.65 25.1 2.67 26.8 2.70 28.7 2.73 29.6 2.75
NOTE:
Specifications are based on the following conditions.
• Power source of specifications: 230 V
• 2 or more indoor units should be connected.
• Pipe length: 24.6 ft (7.5 m), Height difference: 0 ft (0 m) [Outdoor unit - Indoor unit]
• The total ability of connected a indoor unit is from 34,000 Btu up to 54,000 Btu.
• Input in the table are calculated based on the maximum indoor unit input combina-
tions.
- 255 -
6-2. Cooling capacity 6. Capacity table
OUTDOOR UNIT AOU45RLXFZ OUTDOOR UNIT AOU45RLXFZ

Fujitsu ASUH24LPAS Specifications

General

Brand	Fujitsu
Model	ASUH24LPAS
Category	Air Conditioner
Language	English
