Fujitsu ASUH24LPAS User Manual

¢ Floor type
 Unit: kBtu/h, °F
• TC: Total Capacity (kBtu/h), SHC: Sensible Heat Capacity (kBtu/h).
• The data is based on the following conditions:
Pipe length: 24.6 ft (7.5 m), Height difference: 0 ft (0 m) [Outdoor unit - Indoor unit]
MODEL: AGU9RLF
Outdoor temperature
Indoor temperature (°FDB / °FWB)
64.0 / 54.0 70.0 / 60.0 75.0 / 63.0 80.0 / 67.0 85.0 / 71.0 90.0 / 73.0
(°FDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
14.0 7.53 5.14 8.51 5.86 8.97 6.75 9.60 7.58 10.26 8.29 10.58 9.50
23.0 7.53 5.14 8.51 5.86 8.97 6.75 9.60 7.58 10.26 8.29 10.58 9.50
32.0 7.53 5.14 8.51 5.86 8.97 6.75 9.60 7.58 10.26 8.29 10.58 9.50
41.0 7.53 5.14 8.51 5.86 8.97 6.75 9.60 7.58 10.26 8.29 10.58 9.50
50.0 7.53 5.14 8.51 5.86 8.97 6.75 9.60 7.58 10.26 8.29 10.58 9.50
59.0 7.53 5.14 8.51 5.86 8.97 6.75 9.60 7.58 10.26 8.29 10.58 9.50
67.0 7.53 5.14 8.51 5.86 8.97 6.75 9.60 7.58 10.26 8.29 10.58 9.50
77.0 7.53 5.14 8.51 5.86 8.97 6.75 9.60 7.58 10.26 8.29 10.58 9.50
87.0 7.53 5.14 8.51 5.86 8.97 6.75 9.60 7.58 10.26 8.29 10.58 9.50
95.0 7.53 5.14 8.51 5.86 8.97 6.75 9.60 7.58 10.26 8.29 10.58 9.50
104.0 7.12 4.60 8.05 5.25 8.48 6.04 9.08 6.79 9.71 7.43 10.01 8.51
115.0 6.72 4.10 7.59 4.67 8.00 5.38 8.57 6.04 9.16 6.61 9.44 7.57
MODEL: AGU12RLF
Outdoor temperature
Indoor temperature (°FDB / °FWB)
64.0 / 54.0 70.0 / 60.0 75.0 / 63.0 80.0 / 67.0 85.0 / 71.0 90.0 / 73.0
(°FDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
14.0 10.04 6.42 11.34 7.32 11.96 8.43 12.80 9.47 13.68 10.36 14.11 11.87
23.0 10.04 6.42 11.34 7.32 11.96 8.43 12.80 9.47 13.68 10.36 14.11 11.87
32.0 10.04 6.42 11.34 7.32 11.96 8.43 12.80 9.47 13.68 10.36 14.11 11.87
41.0 10.04 6.42 11.34 7.32 11.96 8.43 12.80 9.47 13.68 10.36 14.11 11.87
50.0 10.04 6.42 11.34 7.32 11.96 8.43 12.80 9.47 13.68 10.36 14.11 11.87
59.0 10.04 6.42 11.34 7.32 11.96 8.43 12.80 9.47 13.68 10.36 14.11 11.87
67.0 10.04 6.42 11.34 7.32 11.96 8.43 12.80 9.47 13.68 10.36 14.11 11.87
77.0 10.04 6.42 11.34 7.32 11.96 8.43 12.80 9.47 13.68 10.36 14.11 11.87
87.0 10.04 6.42 11.34 7.32 11.96 8.43 12.80 9.47 13.68 10.36 14.11 11.87
95.0 10.04 6.42 11.34 7.32 11.96 8.43 12.80 9.47 13.68 10.36 14.11 11.87
104.0 9.50 5.75 10.73 6.56 11.31 7.55 12.11 8.48 12.95 9.27 13.35 10.63
115.0 8.96 5.12 10.12 5.83 10.67 6.71 11.42 7.54 12.21 8.25 12.59 9.45
MODEL: AGU15RLF
Outdoor temperature
Indoor temperature (°FDB / °FWB)
64.0 / 54.0 70.0 / 60.0 75.0 / 63.0 80.0 / 67.0 85.0 / 71.0 90.0 / 73.0
(°FDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
14.0 12.54 7.81 14.18 8.91 14.94 10.25 16.00 11.52 17.10 12.60 17.63 14.44
23.0 12.54 7.81 14.18 8.91 14.94 10.25 16.00 11.52 17.10 12.60 17.63 14.44
32.0 12.54 7.81 14.18 8.91 14.94 10.25 16.00 11.52 17.10 12.60 17.63 14.44
41.0 12.54 7.81 14.18 8.91 14.94 10.25 16.00 11.52 17.10 12.60 17.63 14.44
50.0 12.54 7.81 14.18 8.91 14.94 10.25 16.00 11.52 17.10 12.60 17.63 14.44
59.0 12.54 7.81 14.18 8.91 14.94 10.25 16.00 11.52 17.10 12.60 17.63 14.44
67.0 12.54 7.81 14.18 8.91 14.94 10.25 16.00 11.52 17.10 12.60 17.63 14.44
77.0 12.54 7.81 14.18 8.91 14.94 10.25 16.00 11.52 17.10 12.60 17.63 14.44
87.0 12.54 7.81 14.18 8.91 14.94 10.25 16.00 11.52 17.10 12.60 17.63 14.44
95.0 12.54 7.81 14.18 8.91 14.94 10.25 16.00 11.52 17.10 12.60 17.63 14.44
104.0 11.87 6.99 13.41 7.97 14.14 9.18 15.14 10.31 16.18 11.28 16.68 12.92
115.0 11.19 6.22 12.65 7.09 13.34 8.17 14.28 9.17 15.26 10.03 15.73 11.50
- 272 -
6-2. Cooling capacity 6. Capacity table
OUTDOOR UNIT AOU45RLXFZ OUTDOOR UNIT AOU45RLXFZ

Fujitsu ASUH24LPAS Specifications

General

Brand	Fujitsu
Model	ASUH24LPAS
Category	Air Conditioner
Language	English
