Fujitsu ASUH24LPAS User Manual

 Unit: kW, °C
• TC: Total Capacity (kW), SHC: Sensible Heat Capacity (kW).
• The data is based on the following conditions:
Pipe length: 24.6 ft (7.5 m), Height difference: 0 ft (0 m) [Outdoor unit - Indoor unit]
MODEL: ADUH07LUAS1
Outdoor temperature
Indoor temperature (°CDB / °CWB)
17.8 / 12.2 21.1 / 15.6 23.9 / 17.2 26.7 / 19.4 29.4 / 21.7 32.2 / 22.8
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 1.72 1.19 1.95 1.36 2.05 1.57 2.20 1.76 2.35 1.92 2.42 2.20
-5.0 1.72 1.19 1.95 1.36 2.05 1.57 2.20 1.76 2.35 1.92 2.42 2.20
0.0 1.72 1.19 1.95 1.36 2.05 1.57 2.20 1.76 2.35 1.92 2.42 2.20
5.0 1.72 1.19 1.95 1.36 2.05 1.57 2.20 1.76 2.35 1.92 2.42 2.20
10.0 1.72 1.19 1.95 1.36 2.05 1.57 2.20 1.76 2.35 1.92 2.42 2.20
15.0 1.72 1.19 1.95 1.36 2.05 1.57 2.20 1.76 2.35 1.92 2.42 2.20
20.0 1.72 1.19 1.95 1.36 2.05 1.57 2.20 1.76 2.35 1.92 2.42 2.20
25.0 1.72 1.19 1.95 1.36 2.05 1.57 2.20 1.76 2.35 1.92 2.42 2.20
30.0 1.72 1.19 1.95 1.36 2.05 1.57 2.20 1.76 2.35 1.92 2.42 2.20
35.0 1.72 1.19 1.95 1.36 2.05 1.57 2.20 1.76 2.35 1.92 2.42 2.20
40.0 1.63 1.07 1.84 1.22 1.94 1.40 2.08 1.57 2.22 1.72 2.29 1.97
46.1 1.54 0.95 1.74 1.08 1.83 1.25 1.96 1.40 2.10 1.53 2.16 1.75
MODEL: ADUH09LUAS1
Outdoor temperature
Indoor temperature (°CDB / °CWB)
17.8 / 12.2 21.1 / 15.6 23.9 / 17.2 26.7 / 19.4 29.4 / 21.7 32.2 / 22.8
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.21 1.41 2.49 1.61 2.63 1.85 2.81 2.08 3.01 2.28 3.10 2.61
-5.0 2.21 1.41 2.49 1.61 2.63 1.85 2.81 2.08 3.01 2.28 3.10 2.61
0.0 2.21 1.41 2.49 1.61 2.63 1.85 2.81 2.08 3.01 2.28 3.10 2.61
5.0 2.21 1.41 2.49 1.61 2.63 1.85 2.81 2.08 3.01 2.28 3.10 2.61
10.0 2.21 1.41 2.49 1.61 2.63 1.85 2.81 2.08 3.01 2.28 3.10 2.61
15.0 2.21 1.41 2.49 1.61 2.63 1.85 2.81 2.08 3.01 2.28 3.10 2.61
20.0 2.21 1.41 2.49 1.61 2.63 1.85 2.81 2.08 3.01 2.28 3.10 2.61
25.0 2.21 1.41 2.49 1.61 2.63 1.85 2.81 2.08 3.01 2.28 3.10 2.61
30.0 2.21 1.41 2.49 1.61 2.63 1.85 2.81 2.08 3.01 2.28 3.10 2.61
35.0 2.21 1.41 2.49 1.61 2.63 1.85 2.81 2.08 3.01 2.28 3.10 2.61
40.0 2.09 1.26 2.36 1.44 2.49 1.66 2.66 1.86 2.85 2.04 2.93 2.34
46.1 1.97 1.12 2.22 1.28 2.35 1.48 2.51 1.66 2.68 1.81 2.77 2.08
MODEL: ADUH12LUAS1
Outdoor temperature
Indoor temperature (°CDB / °CWB)
17.8 / 12.2 21.1 / 15.6 23.9 / 17.2 26.7 / 19.4 29.4 / 21.7 32.2 / 22.8
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.90 1.85 3.27 2.11 3.45 2.43 3.69 2.73 3.95 2.99 4.07 3.42
-5.0 2.90 1.85 3.27 2.11 3.45 2.43 3.69 2.73 3.95 2.99 4.07 3.42
0.0 2.90 1.85 3.27 2.11 3.45 2.43 3.69 2.73 3.95 2.99 4.07 3.42
5.0 2.90 1.85 3.27 2.11 3.45 2.43 3.69 2.73 3.95 2.99 4.07 3.42
10.0 2.90 1.85 3.27 2.11 3.45 2.43 3.69 2.73 3.95 2.99 4.07 3.42
15.0 2.90 1.85 3.27 2.11 3.45 2.43 3.69 2.73 3.95 2.99 4.07 3.42
20.0 2.90 1.85 3.27 2.11 3.45 2.43 3.69 2.73 3.95 2.99 4.07 3.42
25.0 2.90 1.85 3.27 2.11 3.45 2.43 3.69 2.73 3.95 2.99 4.07 3.42
30.0 2.90 1.85 3.27 2.11 3.45 2.43 3.69 2.73 3.95 2.99 4.07 3.42
35.0 2.90 1.85 3.27 2.11 3.45 2.43 3.69 2.73 3.95 2.99 4.07 3.42
40.0 2.74 1.66 3.10 1.89 3.26 2.18 3.49 2.45 3.74 2.68 3.85 3.07
46.1 2.58 1.48 2.92 1.68 3.08 1.94 3.30 2.18 3.52 2.38 3.63 2.73
- 264 -
6-2. Cooling capacity 6. Capacity table
OUTDOOR UNIT AOU45RLXFZ OUTDOOR UNIT AOU45RLXFZ
