5. Fan performance
5-1. Air velocity distributions
¢
Model: ASYA09KLWA
Measuring conditions
Fan speed Operation mode
HIGH FAN
Top view
Vertical airflow direction louver: Up
Horizontal airflow direction louver: Center
Top view
Vertical airflow direction louver: Up
Horizontal airflow direction louver: Left
- 8 -
5-1. Air velocity distributions 5. Fan performance
WALL MOUNTED ASYA09-12KLWA WALL MOUNTED ASYA09-12KLWA
