2. Dimensions
2-1. Models: ASYA09KLWA and ASYA12KLWA
Unit: mm
805
194
285
¢
Installation space requirement
Provide sufficient installation space for product safety.
Unit: mm
120
or more
2,300 or more
120
or more
150 or more
- 4 -
2-1. Models: ASYA09KLWA and ASYA12KLWA 2. Dimensions
