2. Dimensions
2-1. Models: AOYA09KLWA and AOYA12KLWA
Unit: mm
450
773
700
550
252
275
287
- 21 -
2-1. Models: AOYA09KLWA and AOYA12KLWA 2. Dimensions
OUTDOOR UNIT
AOYA09-12KLWA
OUTDOOR UNIT
AOYA09-12KLWA
