6-2. Model: AOYG12KETA
NOTE: Values mentioned in the table are calculated based on the maximum capacity.
COOLING
Pipe length (m)
5 7.5 10 15 20
Height difference H (m)
Indoor unit is higher than
outdoor unit *1
15 — — — 0.858 0.868
10 — — 0.929 0.872 0.882
7.5 — 0.960 0.933 0.876 0.885
5 0.992 0.964 0.937 0.879 0.889
0 1.000 0.972 0.944 0.887 0.896
Indoor unit is lower than
outdoor unit *2
-5 1.000 0.972 0.944 0.887 0.896
-7.5 — 0.972 0.944 0.887 0.896
-10 — — 0.944 0.887 0.896
-15 — — — 0.887 0.896
HEATING
Pipe length (m)
5 7.5 10 15 20
Height difference H (m)
Indoor unit is higher than
outdoor unit *1
15 — — — 0.896 0.879
10 — — 0.968 0.890 0.879
7.5 — 0.994 0.968 0.896 0.879
5 1.000 0.994 0.968 0.896 0.879
0 1.000 0.994 0.968 0.896 0.879
Indoor unit is lower than
outdoor unit *2
-5 0.995 0.989 0.963 0.891 0.875
-7.5 — 0.987 0.961 0.889 0.873
-10 — — 0.959 0.887 0.871
-15 — — — 0.878 0.862
6-3. Model: AOYG14KETA
NOTE:
Values mentioned in the table are calculated based on the maximum capacity.
COOLING
Pipe length (m)
5 7.5 10 15 20
Height difference H (m)
Indoor unit is higher than
outdoor unit *1
15 — — — 0.893 0.909
10 — — 0.955 0.908 0.924
7.5 — 0.975 0.959 0.912 0.928
5 0.992 0.979 0.963 0.916 0.931
0 1.000 0.987 0.970 0.923 0.939
Indoor unit is lower than
outdoor unit *2
-5 1.000 0.987 0.970 0.923 0.939
-7.5 — 0.987 0.970 0.923 0.939
-10 — — 0.970 0.923 0.939
-15 — — — 0.923 0.939
HEATING
Pipe length (m)
5 7.5 10 15 20
Height difference H (m)
Indoor unit is higher than
outdoor unit *1
15 — — — 0.956 0.938
10 — — 1.004 0.956 0.938
7.5 — 1.013 1.004 0.956 0.938
5 1.000 1.013 1.004 0.956 0.938
0 1.000 1.013 1.004 0.956 0.938
Indoor unit is lower than
outdoor unit *2
-5 0.995 1.008 0.999 0.951 0.938
-7.5 — 1.005 0.997 0.948 0.931
-10 — — 0.994 0.946 0.929
-15 — — — 0.937 0.919
- 60 -
6-2. Model: AOYG12KETA 6. Capacity compensation rate for pipe length and height difference
OUTDOOR UNIT
AOYG07-14KETA
OUTDOOR UNIT
AOYG07-14KETA
