7. Additional charge calculation
7-1. Models: AOYG07KETA and AOYG09KETA
Refrigerant type R32
Factory charge amount g 600
¢ Refrigerant charge
Total pipe length m 15 or less 20 (Max.)
20 g/m
Additional charge amount g 0 100
7-2. Model: AOYG12KETA
Refrigerant type R32
Factory charge amount g 700
¢ Refrigerant charge
Total pipe length m 15 or less 20 (Max.)
20 g/m
Additional charge amount g 0 100
7-3. Model: AOYG14KETA
Refrigerant type R32
Factory charge amount g 850
¢ Refrigerant charge
Total pipe length m 15 or less 20 (Max.)
20 g/m
Additional charge amount g 0 100
- 61 -
