10. Electrical characteristics
Model name AOYG07KETA AOYG09KETA AOYG12KETA AOYG14KETA
Power
supply
Voltage V 230~
Frequency Hz 50
Max operating current *
1
A 9.0
Starting current A 3.0 3.4 5.1 6.8
Wiring
spec. *
2
Circuit breaker current A 15
Power cable
mm
2
1.5
Connection
cable *
3
Cross-
sectional
area
mm
2
1.5
Limited
wiring
length
m 21
NOTES:
• *1: Maximum operating current is the total current of the indoor unit and the outdoor unit.
• *2: Selected sample based on Japan Electrotechnical Standards and Codes Committee E0005.
As the regulations of wire size and circuit breaker differ in each country or region, select appro-
priate devices complied to the regional standard.
• *3: Limit voltage drop to less than 2%. If voltage drop is 2% or more, increase cable conductor
size.
- 67 -
10. Electrical characteristics
OUTDOOR UNIT
AOYG07-14KETA
OUTDOOR UNIT
AOYG07-14KETA
