2. Dimensions
2-1. Models: ASYG07KPCA, ASYG09KPCA, and ASYG12KPCA
Unit: mm
784 224
Outline of indoor unit
for pipe inlet Ø65
for pipe inlet Ø65
43
43
292 13329267
10432148 311
94
84
270
- 4 -
2-1. Models: ASYG07KPCA, ASYG09KPCA, and ASYG12KPCA 2. Dimensions
WALL MOUNTED
ASYG07-12KPCA
WALL MOUNTED
ASYG07-12KPCA
