6. SYSTEM DESIGN
FUNCTION DETAILS5-6.
Functions
Compact
cassette
Slim duct Wall mounted Floor / Ceiling Floor
1) Filter sign
2) Ceiling height
- -
-
3) Outlet directions
- - - -
4) ertica airow direction range contro - - - -
5) Static pressure -
- - -
6) Room temperature control for cooling
7) Room temperature control for heating
8) Auto restart
9) Room temperature sensor switching
10) Remote controller custom code
11) External input control
12) Room temperature sensor switching (Aux.)
13)
Indoor unit fan control for energy saving
for cooling
1) Filter sign
eect appropriate interas or dispaing the ter sign on the indoor unit according to the
estimated amount of dust in the air of the room.
If the indication is not required, select "No indication" (03).
(
... Factory setting)
Setting description Function number Setting value
Standard
11
00
Long interval 01
Short interval 02
No indication 03
Intervals will differ depending on the Indoor unit type as follows.
Setting description
Comapact
Cassette
Slim Duct
Wall
Mounted
Floor /
Ceiling
Floor
Standard 2500 hours 400 hours
Long interval 4400 hours 1000 hours
Short interval 1250 hours 200 hours
2) Ceiling height
Select the appropriate ceiling height according to the place of installation.
(
... Factory setting)
Setting description Function number Setting value
Standard (2.7m)
20
00
High ceiling (3.0m) 01
In case of Cassette type models: The ceiling height values are for the 4-way outlet.
Do not change this setting in the 3-way outlet mode.
7000, 9000 Btu/h models cannot be installed in high
ceilings. Do not change this setting.
- (06 - 84) -
