6. SYSTEM DESIGN
3) Outlet directions
Select the appropriate number of outlet directions according to the installation conditions.
(

... Factory setting)
Setting description Function number Setting value

4-way
22
00
3-way 01
4) Vertical airow direction range control
In a concealed installation, change the setting to "Fixed" (02) to restrict the movement of the
upper air outet so that the airow is on towards the horionta direction.
(

... Factory setting)
Setting description Function number Setting value

Standard
23
00
(Setting forbidden) 01
Fixed (Concealed) 02
5) Static pressure
Select the appropriate static pressure according to the installation conditions.
(

... Factory setting)
Setting description Function number Setting value
0 Pa
26
00
10 Pa 01
20 Pa 02
30 Pa 03
40 Pa 04
50 Pa 05
60 Pa 06
70 Pa 07
80 Pa 08
90 Pa 09

25 Pa [Standard] 31
6) Room temperature control for cooling
Depending on the installed environment, correction of the room temperature sensor may be
required.
Select the appropriate control setting according to the installed environment.
(

... Factory setting)
Setting description Function number Setting value

Standard
30
00
Slightly lower control 01
Lower control 02
Higher control 03
n case o i duct tpe and ooreiing tpe odes n oor consoe instaations seect
"01".
7) Room temperature control for heating
Depending on the installed environment, correction of the room temperature sensor may be
required.
Select the appropriate control setting according to the installed environment.
(

... Factory setting)
Setting description Function number Setting value

Standard
31
00
Lower control 01
Slightly higher control 02
Higher control 03
n case o i duct tpe and ooreiing tpe odes n oor consoe instaations seect
"01".
- (06 - 85) -
