Fujitsu ASYG07LMCE User Manual

4. Capacity table
Capacity tables show each of following values calculated based on the outdoor temperature and
the indoor temperature, under given Airflow Rate (AFR):
For cooling capacity: Total Capacity (TC), Sensible Heat Capacity (SHC), and Input Power (IP)
For heating capacity: Total Capacity (TC) and Input Power (IP)
4-1. Cooling capacity
¢
Model:ASYG07LMCE
AFR
m
3
/h
750
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
20 1.87 1.32 0.33 2.09 1.33 0.33 2.16 1.45 0.33 2.30 1.45 0.34 2.37 1.57 0.34 2.51 1.56 0.34 2.65 1.66 0.35
25 1.78 1.26 0.37 1.98 1.26 0.37 2.05 1.37 0.37 2.18 1.38 0.38 2.25 1.49 0.38 2.39 1.48 0.38 2.52 1.58 0.39
30 1.68 1.19 0.41 1.87 1.19 0.41 1.94 1.30 0.42 2.06 1.30 0.42 2.13 1.41 0.42 2.25 1.40 0.43 2.38 1.49 0.43
35 1.58 1.12 0.45 1.76 1.12 0.46 1.82 1.22 0.46 1.94 1.23 0.46 2.00 1.32 0.47 2.12 1.32 0.47 2.24 1.40 0.47
40 1.41 1.00 0.45 1.57 1.00 0.46 1.62 1.09 0.46 1.73 1.09 0.46 1.78 1.18 0.46 1.89 1.17 0.47 2.00 1.25 0.47
43 1.31 0.92 0.45 1.45 0.93 0.45 1.50 1.01 0.46 1.60 1.01 0.46 1.65 1.09 0.46 1.75 1.09 0.47 1.85 1.16 0.47
¢
Model:ASYG09LMCE
AFR
m
3
/h
750
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
20 2.34 1.62 0.46 2.61 1.63 0.46 2.70 1.77 0.47 2.87 1.78 0.47 2.96 1.92 0.47 3.14 1.91 0.48 3.32 2.04 0.48
25 2.22 1.54 0.51 2.48 1.55 0.52 2.56 1.68 0.52 2.73 1.69 0.53 2.81 1.82 0.53 2.98 1.82 0.54 3.15 1.93 0.54
30 2.10 1.45 0.57 2.34 1.46 0.58 2.42 1.59 0.58 2.58 1.60 0.59 2.66 1.72 0.59 2.82 1.72 0.60 2.98 1.83 0.60
35 1.98 1.37 0.63 2.20 1.38 0.64 2.28 1.50 0.64 2.43 1.50 0.65 2.50 1.62 0.65 2.65 1.61 0.66 2.80 1.72 0.66
40 1.76 1.22 0.63 1.96 1.23 0.64 2.03 1.33 0.64 2.16 1.34 0.65 2.23 1.44 0.65 2.36 1.44 0.66 2.50 1.53 0.66
43 1.63 1.13 0.62 1.82 1.14 0.63 1.88 1.24 0.64 2.00 1.24 0.64 2.07 1.34 0.65 2.19 1.33 0.65 2.31 1.42 0.66
¢
Model:ASYG12LMCE
AFR
m
3
/h
750
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
20 3.18 2.18 0.66 3.55 2.19 0.67 3.67 2.39 0.68 3.91 2.39 0.68 4.03 2.59 0.69 4.27 2.57 0.70 4.51 2.74 0.70
25 3.03 2.07 0.75 3.37 2.08 0.77 3.49 2.27 0.77 3.72 2.27 0.78 3.83 2.45 0.78 4.06 2.44 0.79 4.29 2.60 0.80
30 2.86 1.96 0.84 3.19 1.97 0.86 3.30 2.14 0.86 3.52 2.15 0.87 3.63 2.32 0.87 3.84 2.31 0.88 4.06 2.46 0.89
35 2.69 1.84 0.94 2.99 1.85 0.95 3.09 2.01 0.96 3.30 2.02 0.97 3.40 2.18 0.97 3.60 2.17 0.98 3.81 2.31 0.99
40 2.27 1.64 0.87 2.53 1.65 0.88 2.62 1.79 0.89 2.79 1.80 0.90 2.87 1.94 0.90 3.05 1.94 0.91 3.22 2.06 0.92
43 2.09 1.52 0.87 2.33 1.53 0.89 2.41 1.66 0.89 2.57 1.67 0.90 2.65 1.80 0.90 2.81 1.80 0.91 2.96 1.91 0.92
¢
Model:ASYG14LMCE
AFR
m
3
/h
770
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
20 3.72 2.44 0.77 4.15 2.46 0.78 4.29 2.67 0.79 4.57 2.68 0.80 4.71 2.90 0.80 4.99 2.89 0.81 5.28 3.07 0.82
25 3.54 2.34 0.88 3.94 2.36 0.89 4.08 2.56 0.90 4.34 2.57 0.91 4.48 2.78 0.91 4.75 2.77 0.92 5.02 2.95 0.93
30 3.36 2.31 0.99 3.74 2.32 1.00 3.87 2.52 1.01 4.12 2.53 1.02 4.25 2.73 1.02 4.50 2.72 1.03 4.76 2.90 1.04
35 3.16 2.19 1.10 3.52 2.21 1.11 3.64 2.40 1.12 3.88 2.41 1.13 4.00 2.60 1.14 4.24 2.59 1.15 4.48 2.76 1.16
40 2.30 1.87 0.75 2.56 1.88 0.76 2.65 2.04 0.77 2.83 2.05 0.78 2.91 2.21 0.78 3.09 2.20 0.79 3.26 2.35 0.80
43 2.20 1.84 0.80 2.45 1.85 0.81 2.53 2.01 0.81 2.70 2.02 0.82 2.78 2.18 0.83 2.95 2.17 0.83 3.12 2.31 0.84
- 7 -
WALL MOUNTED ASYG07-14LMCE

Fujitsu ASYG07LMCE Specifications

General

Type	Air conditioner indoor unit
Timer	Yes
Ionizer	-
Multi-split	No
Hose diameter	6.35 mm
Product color	White
Gas hose diameter	9.52 mm
Drain hose diameter	13.8 mm
Dehumidifying capacity	1 l/h
Air conditioner functions	Cooling, Heating
Cooling capacity in watts (max)	3000 W
Cooling capacity in watts (min)	500 W
Heating capacity in watts (max)	3400 W
Cooling capacity in watts (nominal)	2000 W
Heating capacity in watts (nominal) (Warmer heating season)	- W
Seasonal efficiency rating (heating) (SCOP) (Average heating season)	4.1
Current	7.5 A
AC input voltage	230 V
AC input frequency	50 Hz
Design load (cooling)	2 kW
Hourly energy consumption (cooling)	- kWh
Design load (heating) (Warmer heating season)	- kW
Design load (heating) (Average heating season)	2.3 kW
Indoor unit type	Wall-mountable
Indoor unit depth	204 mm
Indoor unit width	870 mm
Indoor unit height	270 mm
Indoor unit weight	8500 g
Indoor units quantity	1
Heating airflow (indoor unit)	750 m³/h
Indoor unit sound power level	40 dB
Indoor unit noise level (low speed)	32 dB
Indoor unit noise level (high speed)	43 dB
Outdoor unit noise level	- dB
