1. Specifications
Type
Wall mounted
Inverter heat pump
Model name ASYG07LMCE ASYG09LMCE ASYG12LMCE ASYG14LMCE
Power supply 230 V ~ 50 Hz
Available voltage range 198—264 V
Capacity
Cooling
Rated
kW 2.00 2.50 3.40 4.00
Btu/h 6,800 8,500 11,600 13,600
Min.—Max.
kW 0.5—3.0 0.5—3.2 0.9—3.9 0.9—4.4
Btu/h 1,700—10,200 1,700—10,900 3,100—13,300 3,100—15,000
Heating
Rated
kW 3.00 3.20 4.00 5.00
Btu/h 10,200 10,900 13,600 17,000
Min.—Max.
kW 0.5—3.4 0.5—4.0 0.9—5.3 0.9—6.0
Btu/h 1,700—11,600 1,700—13,600 3,100—18,000 3,100—20,400
Input power
Cooling
Rated
kW
0.465 0.65 0.97 1.135
Min.—Max. 0.25—1.29 0.25—1.29 0.25—1.40 0.25—1.98
Heating
Rated 0.685 0.730 1.02 1.365
Min.—Max. 0.25—1.63 0.25—1.63 0.25—1.98 0.25—2.32
Fan
HIGH
W
30 32
MED 20 23
LOW 10 12
QUIET 4 6
Current
Cooling
Rated A
2.5 3.2 4.6 5.3
Heating 3.3 3.5 4.8 6.3
EER Cooling
kW/kW
4.30 3.85 3.50 3.52
COP Heating 4.38 4.38 3.92 3.66
Sensible capacity Cooling kW 1.2 1.6 2.2 3.2
Power factor
Cooling
%
81 88 91 93
Heating 90 90 92 94
Moisture removal L/h (pints/h) 1.0 (1.8) 1.3 (2.3) 1.8 (3.2) 2.1 (3.7)
Maximum operating current *1
Cooling
A
6.0 6.0 6.5 9.0
Heating 7.5 7.5 9.0 10.5
Fan
Airflow rate
Cooling
HIGH
m
3
/h
750 770
MED 640 680
LOW 480 530
QUIET 310 360
Heating
HIGH 750 770
MED 640 680
LOW 520 560
QUIET 330 380
Type × Q'ty Cross flow fan × 1
Motor output W 30
Sound pressure level *2
Cooling
HIGH
dB (A)
43 44
MED 40 40
LOW 32 33
QUIET 21 25
Heating
HIGH 43 44
MED 38 40
LOW 33 35
QUIET 22 27
Heat exchanger type
Dimensions (H × W × D)
mm
Main: 320 × 630 × 20
Sub: 84 × 630 × 13.3
Fin pitch Man: 1.1, Sub: 1.4
Rows × Stages Main: 2 × 20, Sub: 1 × 4
Pipe type Copper tube
Fin type Aluminum
Enclosure
Material Polystyrene
Color
White + Pearl white (painted)
Approximate color of Munsell N 9.25/
Dimensions
(H × W × D)
Net
mm
270 × 870 × 204
Gross 270 × 925 × 336
Weight
Net
kg
8.5
Gross 11
Connection pipe
Size
Liquid
mm (in)
Ø 6.35 (Ø 1/4)
Gas Ø 9.52 (Ø 3/8) Ø 12.7 (Ø 1/2)
Method Flare
Drain hose
Material PP+LLDPE
Size mm Ø 13.8 (I.D.), Ø 15.8 to Ø 16.7 (O.D.)
Operation range
Cooling
°C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Remote controller type Wireless (Wired [option])
NOTES:
• Specifications are based on the following conditions:
– Cooling: Indoor temperature of 27 °CDB/19 °CWB, and outdoor temperature of 35 °CDB/24 °CWB.
– Heating: Indoor temperature of 20 °CDB/15 °CWB, and outdoor temperature of 7 °CDB/6 °CWB.
– Pipe length: 5 m, Height difference: 0 m. (Between outdoor unit and indoor unit.)
• Protective function might work when using it outside the operation range.
• *1: Maximum current is maximum value when operated within the operation range.
• *2: Sound pressure level:
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
DESIGN & TECHNICAL MANUAL
- 2 -
WALL MOUNTED
ASYG07-14LMCE
