Fujitsu ASYG09LLCE Service Instruction

(2) Press the MODE button for at least 5 seconds to display the current signal code.
(initially set to ).
(4) Press the MODE button again to return to the clock display.
The signal code will be changed.
Selecting the Remote Controller Signal Code
(3) Press the SET TEMP.( ) ( ) buttons to change the signal code
between .
Match the code on the display to the air conditioner signal code.
If no buttons are pressed within 30 seconds after the signal code is displayed,
the system returns to the original clock display.
In this case, start again from step 1.
The air conditioner signal code is set to A prior to shipment.
CAUTION
(1) Press the START/STOP( ) button until only the clock is displayed
on the remote controller display.
03-07

Fujitsu ASYG09LLCE Specifications

General

Type	Air conditioner indoor unit
Multi-split	-
Product color	White
Inverter technology	Yes
Refrigerating medium	R410A
Air conditioner functions	Cooling, Dehumidifying, Heating
Refrigerating medium weight	650 g
Cooling capacity in watts (nominal)	- W
Operating temperature (cooling) (T-T)	-10 - 43 °C
Operating temperature (heating) (T-T)	-15 - 24 °C
Heating capacity in watts (nominal) (Average heating season)	3000 W
Airflow	1670 m³/h
Outdoor unit noise level	- dB
AC input voltage	230 V
AC input frequency	50 Hz
Design load (cooling)	- kW
Annual energy consumption (cooling)	127 kWh
Hourly energy consumption (cooling)	- kWh
Indoor unit type	Wall-mountable
Indoor unit depth	206 mm
Indoor unit width	820 mm
Indoor unit height	262 mm
Indoor unit weight	7000 g
Indoor unit noise level (high speed)	720 dB
