DIMENSIONS
262 mm
15.8 to 16.7
206 mm820 mm
2014.02.06 2
INDOOR UNIT
Drain hose
OUTDOOR UNIT
Diameter
Outside
Inside : 13.8 mm
25
660 mm
600 mm
20 290 mm60
454 mm
540 mm
