PARTS
7
2
2
5
4
6
1
INDOOR UNIT
2014.02.24 11
7
8
6 Front Panel 9332545012
Bracket panel
1
Wire Cover 9332544008
4
Wire
shield
Remote Control 9332598001
Intake Grille (FUJITSU)
9332818062
5 Receiver Window 9332546019
3
2
Panel Cover 9332559019
Ref. Description Part number
Air Filter 9332549003
Louver Assy 9333342016
8
3
