INDOOR UNIT
Control box
12
Terminal 9900720001
Main PCB (ASYG09LLTB-T) 9709170243
13
Earth terminal
Control Box11
Cover Shield
9332542004
Box shield assy
12
Main PCB (ASYG12LLTB-T) 970917025012
15 Room Thermistor Holder 9316895003
Ref. Description Part number
14
-- Thermistor Assy 9900824006
Display Assy 9709173039
2014.02.24
12
11
15
14
13
