Page #8 background image
1
2
3
4
5
6
7
A
2
1
3
A
VCC
OUT
GND
A
A
IC201
GP1UM261R
R202
47
<1/4W>
5V
C203
0.1
<F>
+
C202
47/
10V
SW201
KSHC611BT-PBT
5V
5V
D201 SLR-343MC GREEN
D203 SLR-343MC GREEN
D202 SLR-343DC ORANGE
CN201
S7B-PH-K-S
WHITE
INDOOR UNIT
INDICATOR PCB
K11
CO-1200HSE-D0
2013.12.18 7
