¢ Casing total assy
150
151
152
Item no. Part no. Part name Service part
150 9319776002 Outlet cover assy ♦
151 9319173085 Motor case assy ♦
152 9319172101 Casing assy ♦
2-1. Models: ASYG09KHCA, ASYG12KHCA, and ASYG14KHCA - (02-5) - 2. Indoor unit parts list
TECHNICAL DATA
AND PARTS LIST
TECHNICAL DATA
AND PARTS LIST
