01-09
Switch the airflow [Auto] at cooling mode, and the indoor fan motor will run as shown in Fig.
When the defrost operation starts, the indoor fan runs according to cool air preventtion control for 20 seconds.
And the fan is stopped if 20 seconds have passed.
When 60 seconds have passed after defrost operation is released,
the fan runs according to cool air preventtion control
7. MOISTURE RETURN PREVENTION CONTROL (COOLING AND DRY MODE)
9. DEFROST OPERATION
Switch the airflow at cooling mode, and the indoor fan motor will run as shown in the above Fig.
It depends on the Function setting "Indoor unit fan control for energy saving".
8. CONTROL FOR ENERGY SAVING (COOLING MODE)
Fig. : Indoor fan control
Compressor
ON
OFF
Indoor fan
Setting air flow
Indoor fan
(as shown in the table)
S-Lo
OFF
10 30 60 180 60 180 60 10 30
(sec)
Table : Indoor fan speed
X zone J zone
ASYG09/12KMCB
680rpm 660rpm 680rpm
ASYG14KMCB
750rpm 730rpm 750rpm
Dry
Cooling
