OUTDOOR UNIT
AOYG12LLC
2012.03.05 22
42 Compressor Assy 9332603002
46 3 way Valve Assy 9332653007
47 Capillary Assy 9332605006
43 Solenoid 9970110054
41 Condenser Total Assy 9332593006
45 Muffler 9317398008
44 4 way Valve Assy 9332656008
48 2 way Valve Assy 9332652000
Ref. Description Part number
42
48
47
45
46
41
44
43
