Page #9 background imageLoading...
Page #9 background image
5V
5V
1
2
3
4
5
6
7
A
A
A
A
5V
+
R202
47
<1/4W>
C203
0.1
<F>
C202
47/
10V
SW201
KSHC611BT
I C201
GP1UM261RKVF
2
1
3
VCC
OUT
GND
CN201
S7B-PH-K-S
WHITE
D203 SLR-343MC GREEN
D201 SLR-343MC GREEN
D202 SLR-343DC ORANGE
MANUAL AUTO
SWITCH
INDOOR UNIT
INDICATOR PCB
K11CO-1100HSE-D0
2011.11.17 8
