Fujitsu ASYG12LLCE

5. Fan performance
5-1. Air velocity distributions
¢
Models:ASYG07LLCE, ASYG09LLCE, and ASYG12LLCE
Measuring conditions
Fan speed Operation mode
HIGH FAN
Top view
Vertical airflow direction louver: Up
Horizontal airflow direction louver: Center
2.0
1.0
0.5
2
1
0
1
2
Unit: m/s(m)
(m)
012345678
Top view
Vertical airflow direction louver: Up
Horizontal airflow direction louver: Left & Right
2.0
1.0
1.0
0.5
0.5
3
2
1
0
1
2
3
Unit: m/s(m)
(m)
012345678
Side view
Vertical airflow direction louver: Up
Horizontal airflow direction louver: Center
2.0
1.0
0.5
3
2
1
0
Unit: m/s(m)
(m)
012345678
Side view
Vertical airflow direction louver: Down
Horizontal airflow direction louver: Center
2.0
1.0
0.5
3
2
1
0
Unit: m/s(m)
(m)
012345678
- 9 -
WALL MOUNTED ASYG07-12LLCE
