Specifications
Controller
Unit: mm
Front view Side view Rear view
170
19
56
Top view
Size (H × W × D) mm 170 × 56 × 19
Weight g 85 (without batteries)
NOTE: Actual number of buttons might be different from the figure above.
Holder
Unit: mm
Front view Side view Bottom view
60.4
30.2
Ø 3.5
3.5 x 6.5
(hole)
(hole)
26.2
25.595
154.7
Size (H × W × D) mm 154.7 × 60.4 × 26.2
Weight g 28
DESIGN & TECHNICAL MANUAL
- 160 -
MULTI TYPE
5, 6 ROOMS TYPE
