Fujitsu ASYG12LMCE User Manual

Indoor unit connecting
capacity
Outdoor temperature
Indoor temperature
16.0 °CDB 18.0 °CDB 20.0 °CDB 22.0 °CDB 24.0 °CDB
kBtu/h °CDB °CWB TC IP TC IP TC IP TC IP TC IP
54
-15.0
-16.0 10.83 5.10 10.31 5.10 9.90 5.10 9.69 5.09 9.49 5.08
-10.0 -11.0 12.04 5.10 11.48 5.10 11.10 5.10 10.86 5.09 10.63 5.08
-5.0 -7.0 13.43 5.10 12.87 5.10 12.40 5.10 12.21 5.09 12.03 5.07
0.0 -2.0 15.48 5.10 14.89 5.10 14.30 5.10 13.95 5.07 13.61 5.05
5.0 3.0 17.68 5.10 16.85 5.10 15.60 5.10 15.08 4.95 14.56 4.80
7.0 6.0 18.50 4.77 17.40 4.68 16.00 4.59 15.25 4.36 14.50 4.12
10.0 8.0 18.37 4.77 17.28 4.68 16.00 4.59 15.26 4.46 14.52 4.33
15.0 10.0 18.34 4.49 17.17 4.40 16.00 4.28 15.32 4.15 14.63 4.02
20.0 15.0 17.37 3.89 16.28 3.81 15.27 3.70 14.68 3.58 14.08 3.47
24.0 18.0 16.35 3.55 15.41 3.48 14.55 3.38 14.30 3.35 14.04 3.31
53
-15.0
-16.0 10.83 5.10 10.31 5.10 9.90 5.10 9.69 5.09 9.49 5.08
-10.0 -11.0 12.04 5.10 11.48 5.10 11.10 5.10 10.86 5.09 10.63 5.08
-5.0 -7.0 13.43 5.10 12.87 5.10 12.40 5.10 12.21 5.09 12.03 5.07
0.0 -2.0 15.48 5.10 14.89 5.10 14.30 5.10 13.95 5.07 13.61 5.05
5.0 3.0 17.68 5.10 16.85 5.10 15.60 5.10 15.08 4.95 14.56 4.80
7.0 6.0 18.50 4.77 17.40 4.68 16.00 4.59 15.25 4.36 14.50 4.12
10.0 8.0 18.37 4.77 17.28 4.68 16.00 4.59 15.26 4.46 14.52 4.33
15.0 10.0 18.34 4.49 17.17 4.40 16.00 4.28 15.32 4.15 14.63 4.02
20.0 15.0 17.37 3.89 16.28 3.81 15.27 3.70 14.68 3.58 14.08 3.47
24.0 18.0 16.35 3.55 15.41 3.48 14.55 3.38 14.30 3.35 14.04 3.31
52
-15.0
-16.0 10.83 5.10 10.31 5.10 9.90 5.10 9.69 5.09 9.49 5.08
-10.0 -11.0 12.04 5.10 11.48 5.10 11.10 5.10 10.86 5.09 10.63 5.08
-5.0 -7.0 13.43 5.10 12.87 5.10 12.40 5.10 12.21 5.09 12.03 5.07
0.0 -2.0 15.48 5.10 14.89 5.10 14.30 5.10 13.95 5.07 13.61 5.05
5.0 3.0 17.68 5.10 16.85 5.10 15.60 5.10 15.08 4.95 14.56 4.80
7.0 6.0 18.50 4.77 17.40 4.68 16.00 4.59 15.25 4.36 14.50 4.12
10.0 8.0 18.37 4.77 17.28 4.68 16.00 4.59 15.26 4.46 14.52 4.33
15.0 10.0 18.34 4.49 17.17 4.40 16.00 4.28 15.32 4.15 14.63 4.02
20.0 15.0 17.37 3.89 16.28 3.81 15.27 3.70 14.68 3.58 14.08 3.47
24.0 18.0 16.35 3.55 15.41 3.48 14.55 3.38 14.30 3.35 14.04 3.31
51
-15.0
-16.0 10.83 5.10 10.31 5.10 9.90 5.10 9.69 5.09 9.49 5.08
-10.0 -11.0 12.04 5.10 11.48 5.10 11.10 5.10 10.86 5.09 10.63 5.08
-5.0 -7.0 13.43 5.10 12.87 5.10 12.40 5.10 12.21 5.09 12.03 5.07
0.0 -2.0 15.48 5.10 14.89 5.10 14.30 5.10 13.95 5.07 13.61 5.05
5.0 3.0 17.68 5.10 16.85 5.10 15.60 5.10 15.08 4.95 14.56 4.80
7.0 6.0 18.50 4.77 17.40 4.68 16.00 4.59 15.25 4.36 14.50 4.12
10.0 8.0 18.37 4.77 17.28 4.68 16.00 4.59 15.26 4.46 14.52 4.33
15.0 10.0 18.34 4.49 17.17 4.40 16.00 4.28 15.32 4.15 14.63 4.02
20.0 15.0 17.37 3.89 16.28 3.81 15.27 3.70 14.68 3.58 14.08 3.47
24.0 18.0 16.35 3.55 15.41 3.48 14.55 3.38 14.30 3.35 14.04 3.31
50
-15.0
-16.0 10.83 5.10 10.31 5.10 9.90 5.10 9.69 5.09 9.49 5.08
-10.0 -11.0 12.04 5.10 11.48 5.10 11.10 5.10 10.86 5.09 10.63 5.08
-5.0 -7.0 13.43 5.10 12.87 5.10 12.40 5.10 12.21 5.09 12.03 5.07
0.0 -2.0 15.48 5.10 14.89 5.10 14.30 5.10 13.95 5.07 13.61 5.05
5.0 3.0 17.68 5.10 16.85 5.10 15.60 5.10 15.08 4.95 14.56 4.80
7.0 6.0 18.50 4.77 17.40 4.68 16.00 4.59 15.25 4.36 14.50 4.12
10.0 8.0 18.37 4.77 17.28 4.68 16.00 4.59 15.26 4.46 14.52 4.33
15.0 10.0 18.34 4.49 17.17 4.40 16.00 4.28 15.32 4.15 14.63 4.02
20.0 15.0 17.37 3.89 16.28 3.81 15.27 3.70 14.68 3.58 14.08 3.47
24.0 18.0 16.35 3.55 15.41 3.48 14.55 3.38 14.30 3.35 14.04 3.31
49
-15.0
-16.0 10.83 5.10 10.31 5.10 9.90 5.10 9.69 5.09 9.49 5.08
-10.0 -11.0 12.04 5.10 11.48 5.10 11.10 5.10 10.86 5.09 10.63 5.08
-5.0 -7.0 13.43 5.10 12.87 5.10 12.40 5.10 12.21 5.09 12.03 5.07
0.0 -2.0 15.48 5.10 14.89 5.10 14.30 5.10 13.95 5.07 13.61 5.05
5.0 3.0 17.68 5.10 16.85 5.10 15.60 5.10 15.08 4.95 14.56 4.80
7.0 6.0 18.50 4.77 17.40 4.68 16.00 4.59 15.25 4.36 14.50 4.12
10.0 8.0 18.37 4.77 17.28 4.68 16.00 4.59 15.26 4.46 14.52 4.33
15.0 10.0 18.34 4.49 17.17 4.40 16.00 4.28 15.32 4.15 14.63 4.02
20.0 15.0 17.37 3.89 16.28 3.81 15.27 3.70 14.68 3.58 14.08 3.47
24.0 18.0 16.35 3.55 15.41 3.48 14.55 3.38 14.30 3.35 14.04 3.31
48
-15.0
-16.0 10.83 5.10 10.31 5.10 9.90 5.10 9.69 5.09 9.49 5.08
-10.0 -11.0 12.04 5.10 11.48 5.10 11.10 5.10 10.86 5.09 10.63 5.08
-5.0 -7.0 13.43 5.10 12.87 5.10 12.40 5.10 12.21 5.09 12.03 5.07
0.0 -2.0 15.48 5.10 14.89 5.10 14.30 5.10 13.95 5.07 13.61 5.05
5.0 3.0 17.68 5.10 16.85 5.10 15.60 5.10 15.08 4.95 14.56 4.80
7.0 6.0 18.50 4.77 17.40 4.68 16.00 4.59 15.25 4.36 14.50 4.12
10.0 8.0 18.37 4.77 17.28 4.68 16.00 4.59 15.26 4.46 14.52 4.33
15.0 10.0 18.34 4.49 17.17 4.40 16.00 4.28 15.32 4.15 14.63 4.02
20.0 15.0 17.37 3.89 16.28 3.81 15.27 3.70 14.68 3.58 14.08 3.47
24.0 18.0 16.35 3.55 15.41 3.48 14.55 3.38 14.30 3.35 14.04 3.31
47
-15.0
-16.0 10.83 5.10 10.31 5.10 9.90 5.10 9.69 5.09 9.49 5.08
-10.0 -11.0 12.04 5.10 11.48 5.10 11.10 5.10 10.86 5.09 10.63 5.08
-5.0 -7.0 13.43 5.10 12.87 5.10 12.40 5.10 12.21 5.09 12.03 5.07
0.0 -2.0 15.48 5.10 14.89 5.10 14.30 5.10 13.95 5.07 13.61 5.05
5.0 3.0 17.68 5.10 16.85 5.10 15.60 5.10 15.08 4.95 14.56 4.80
7.0 6.0 18.50 4.77 17.40 4.68 16.00 4.59 15.25 4.36 14.50 4.12
10.0 8.0 18.37 4.77 17.28 4.68 16.00 4.59 15.26 4.46 14.52 4.33
15.0 10.0 18.34 4.49 17.17 4.40 16.00 4.28 15.32 4.15 14.63 4.02
20.0 15.0 17.37 3.89 16.28 3.81 15.27 3.70 14.68 3.58 14.08 3.47
24.0 18.0 16.35 3.55 15.41 3.48 14.55 3.38 14.30 3.35 14.04 3.31
46
-15.0
-16.0 10.83 5.10 10.31 5.10 9.90 5.10 9.69 5.09 9.49 5.08
-10.0 -11.0 12.04 5.10 11.48 5.10 11.10 5.10 10.86 5.09 10.63 5.08
-5.0 -7.0 13.43 5.10 12.87 5.10 12.40 5.10 12.21 5.09 12.03 5.07
0.0 -2.0 15.48 5.10 14.89 5.10 14.30 5.10 13.95 5.07 13.61 5.05
5.0 3.0 17.68 5.10 16.85 5.10 15.60 5.10 15.08 4.95 14.56 4.80
7.0 6.0 18.50 4.77 17.40 4.68 16.00 4.59 15.25 4.36 14.50 4.12
10.0 8.0 18.37 4.77 17.28 4.68 16.00 4.59 15.26 4.46 14.52 4.33
15.0 10.0 18.34 4.49 17.17 4.40 16.00 4.28 15.32 4.15 14.63 4.02
20.0 15.0 17.37 3.89 16.28 3.81 15.27 3.70 14.68 3.58 14.08 3.47
24.0 18.0 16.35 3.55 15.41 3.48 14.55 3.38 14.30 3.35 14.04 3.31
- 377 -
OUTDOOR UNIT AOYG45LBLA6

Fujitsu ASYG12LMCE Specifications

General

Type	Air conditioner indoor unit
Multi-split	-
Product color	White
Inverter technology	Yes
Refrigerating medium	R410A
Air conditioner functions	Cooling, Dehumidifying, Heating
Refrigerating medium weight	850 g
Cooling capacity in watts (nominal)	- W
Operating temperature (cooling) (T-T)	-10 - 43 °C
Operating temperature (heating) (T-T)	-15 - 24 °C
Airflow	750 m³/h
Outdoor unit noise level	- dB
Indoor unit type	Wall-mountable
Indoor unit depth	204 mm
Indoor unit width	870 mm
Indoor unit height	270 mm
Indoor unit weight	8500 g
Indoor unit noise level (high speed)	43 dB
AC input voltage	230 V
AC input frequency	50 Hz
Design load (cooling)	- kW
Energy efficiency class (cooling)	A++
Hourly energy consumption (cooling)	- kWh
