Fujitsu ASYG14LTCB User Manual

-
(
02 - 03
)
-
OUTDOOR UNIT AO

G09-14LT
OUTDOOR UNIT AO

G09-14LT
MODEL

:AO

G12LT, AO

G14LT
(Unit : mm)
INSTALLATION PLACE

600 mm or more
100 mm or more
200 mm or more
100 mm or more
250 mm or more
(Service space)
CAUTION
In the area with heavy snowfall, if the intake and outlet
of outdoor unit is blocked with snow, it might become
difficult to get warm and it is likely to cause of the break-
down. Construct a canopy or baffle board stand.
If the space is larger that is stated, the condition will be the same as that are no obstacles.
790
Top view
Front view
Side view
18
62
290
18
20
20
9
110
620
209
352
175
320
4-ø11.3mm hole
540
Air flow
ø20 hole
Bottom view
(6x20=120) (6x20=120)
25
23
25 23
55
55
(
10
)
(
10
)
(
10
)
20
20
hole
17.5
25
1010
hole
102
