WALL MOUNTED TYPE AS

G09-14LT
WALL MOUNTED TYPE AS

G09-14LT
SPECIFICATIONS3.
Note:
Specifications are based on the following conditions
Cooling:Indoor temperature of 27 °CDB/19 °CWB.and outdoor temperature of 35 °CDB/24 °CWB.
Heating:Indoor temperature of 20 °CDB/15 °CWB.and outdoor temperature of 7° CDB/6 °CWB.
Pipe length:5m,Height difference:0m(Outdoor unit-Indoor unit)
The maximum current is the maximum value when the operated within the operation range(temperature).
The protective function might work when using it outside the operation range.
Type
WALL MOUNTED
INVERTER HEAT PUMP
Model name AS

G09LTCB AS

G12LTCB AS

G14LTCB
Power source 230V~ 50Hz
Available voltage range 198-264V~ 50Hz
European energy label
CoolingAAA
HeatingAAA
Capacity
Cooling
Rated
kW 2.50 3.50 4.20
Btu/h 8,500 11,900 14,300
Min-Max
kW 0.9-3.5 1.1-4.0 0.9-5.4
Btu/h 3,100-11,900 3,800-13,600 3,100-18,400
Heating
Rated
kW 3.20 4.00 5.40
Btu/h 10,900 13,600 18,400
Min-Max
kW 0.9-5.4 0.9-6.5 0.9-7.0
Btu/h 3,100-18,400 3,100-22,200 3,100-23,900
Input power
Cooling
Rated
kW
0.505 0.850 1.160
Min-Max 0.25-1.26 0.20-1.70 0.18-2.16
Heating
Rated 0.660 0.910 1.380
Min-Max 0.25-2.28 0.20-2.62 0.17-3.30
Current
Cooling
Rated
A
2.6 4.0 5.1
Max 6.5 9.0 9.5
Heating
Rated 3.3 4.3 6.1
Max 10.0 11.5 14.5
EER Cooling
kW/kW
4.95 4.12 3.62
COP Heating 4.85 4.40 3.91
SENSIBLE CAPACITY Cooling kW 1.62 2.28 2.78
POWER FACTOR
Cooling
%
84 92 99
Heating 87 92 98
Moisture removal l/h(pints/h) 1.3(2.3) 1.8(3.2) 2.1(3.7)
FAN
Airflow
rate
Cooling
High
m
3
/h
800 850 900
Med 640 670 740
Low 550 550 570
Quiet 330 330 390
Heating
High 800 850 950
Med 670 710 740
Low 550 550 600
Quiet 330 330 430
Type× Q’ty Cross flow fanx1
Motor output W 29
Sound pressure level
Cooling
High
dB(A)
42 43 45
Med 36 37 40
Low 32 32 33
Quiet 21 21 25
Heating
High 42 43 45
Med 37 38 40
Low 32 32 34
Quiet 21 21 27
Heat exchanger type
Dimensions
(H×W×D)
mm
320x690x20
Sub 84x690x13.3
Fin pitch
1.1
Sub 1.4
Rows Stages
2x20
Sub 1x4
Pipe type Copper
Fin type Aluminium
Enclosure
Material Polystyrene
Colour
White
Approximate colour of MUNSELL N9.3/
Dimensions
(H×W×D)
Net
mm
282x870x185
Gross 247x920x373
Weight
Net
kg
9.5
Gross 12
Connection pipe
Size
Liquid
mm
Ø6.35(Ø1/4in)
Gas Ø9.52(Ø3/8in) Ø12.70(Ø1/2in)
Method Flare
Operation range
Cooling
°C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Remote controller type Wireless
Drain pipe
Material PP+LLDPE
Size mm
Outer diameter:15.8 to 16.7
Inner diameter:13.8

Fujitsu ASYG14LTCB Specifications

General

Brand	Fujitsu
Model	ASYG14LTCB
Category	Air Conditioner
Language	English
