2. Dimensions
2-1. Models: ASYG18KMTE and ASYG24KMTE
Unit: mm
for pipe inlet Ø65
50
60
430
52
980 240
280
Outline of indoor unit
for pipe inlet Ø65
400413 9077
50
72
418
91
417
482
510
- 4 -
2-1. Models: ASYG18KMTE and ASYG24KMTE 2. Dimensions
WALL MOUNTED
ASYG18-24KMTE
WALL MOUNTED
ASYG18-24KMTE
