Fujitsu ASYG30LMTA User Manual

- 53 -
OUTDOOR UNIT AOYG30, 36LMTA
 Multiple outdoor unit installation
• When the upper space is open:
• When there is an obstruction in the upper space:
Unit: mm
When there are obstacles at the rear only. When there are obstacles at the front only.
When there are obstacles at the front and rear.
Unit: mm
When there are obstacles at the rear and above.
300
250 or more
or more
1,500 or more
250 or more
500 or more
1,500 or more
250 or more
1,500 or more
500 or more
250 or more
250 or more
Max. 300
1,500 or more
