Fujitsu AU*24LUAR - Page 90

SERVICE PARTS INFORMATION 6
Check Point : AU*24LUAR
Red - Blue
Red - Black
White - Red
Read Wire
8%
96.3
54.7
8%
185 8%
Resistance value
(AC)
Thermal protector
Pr
BLUE
RED
BLACK
WHITE
150°C
at 20°C
Outdoor Unit Fan Motor
Check each winding resistance of the motor
If Resistance value is abnormal, replace motor.
07-34
