Fujitsu AU*24LUAR - Capacity Table

08-01
MODEL : AU*24LUAR / AO*24LMAKL
COOLING
HEATING
AFR 20.8
(°CDB) TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
0 4.92 4.28 0.47 5.02 4.04 0.48 5.12 4.27 0.48 5.26 4.44 0.49 5.33 4.41 0.49 5.44 4.33 0.50 5.49 4.29 0.50 5.54 4.47 0.50
5 5.06 4.37 0.59 5.17 4.14 0.60 5.30 4.41 0.61 5.49 4.63 0.62 5.56 4.61 0.62 5.70 4.54 0.63 5.76 4.50 0.63 5.82 4.70 0.64
10 6.00 5.18 0.92 6.15 4.91 0.94 6.30 5.23 0.95 6.55 5.53 0.97 6.65 5.51 0.98 6.83 5.45 0.99 6.91 5.41 1.00 6.99 5.65 1.00
15 5.64 4.85 1.01 5.78 4.58 1.04 5.93 4.91 1.05 6.16 5.20 1.07 6.26 5.18 1.08 6.44 5.13 1.09 6.52 5.10 1.10 6.60 5.35 1.11
20 5.53 4.74 1.14 5.65 4.47 1.16 5.79 4.79 1.17 6.01 5.07 1.20 6.11 5.06 1.21 6.28 5.01 1.23 6.37 4.99 1.24 6.45 5.24 1.25
25 7.16 6.16 1.86 7.34 5.83 1.88 7.50 6.22 1.90 7.78 6.57 1.92 7.90 6.54 1.94 8.12 6.47 1.96 8.22 6.44 1.97 8.31 6.74 1.98
30 6.84 5.85 2.09 7.03 5.57 2.21 7.19 5.96 2.12 7.46 6.30 2.16 7.59 6.28 2.17 7.81 6.23 2.20 7.91 6.20 2.21 8.02 6.52 2.23
35 7.25 6.18 2.88 7.39 5.82 2.89 7.58 6.26 2.92 7.86 6.64 2.96 8.00 6.62 2.98 8.26 6.58 3.02 8.38 6.56 3.04 8.50 6.92 3.06
40 6.83 5.80 3.20 6.93 5.45 3.21 7.09 5.86 3.23 7.38 6.24 3.28 7.52 6.23 3.30 7.78 6.20 3.35 7.91 6.19 3.37 8.04 6.56 3.42
43 6.49 5.48 3.31 6.60 5.17 3.32 6.76 5.57 3.34 7.05 5.96 3.39 7.20 5.96 3.41 7.46 5.94 3.46 7.61 5.94 3.48 7.75 6.31 3.51
Outdoor temperature
19°CWB
21°CWB
22°CWB
23°CWB
12°CWB
15°CWB
16°CWB
18°CWB
Indoor temperature
18°CDB
21°CDB
23°CDB
26°CDB
27°CDB
29°CDB
30°CDB
32°CDB
AFR 20.8
AFR: Air flow rate (m
3
/min)
TC : Total capacity (kW)
(°CDB) (°CWB) TC PI TC PI TC PI TC PI TC PI TC PI TC PI SHC: Sensible Heat capacity (kW)
-10 -11 6.92 3.04 6.81 3.13 6.60 3.23 6.39 3.32 6.28 3.37 6.07 3.47 5.86 3.51 PI : Power Input (kW)
-5 -6 6.80 3.05 6.71 3.14 6.52 3.23 6.33 3.31 6.23 3.36 6.04 3.45 5.85 3.49
0 -1 7.09 3.01 7.00 3.08 6.82 3.16 6.65 3.24 6.56 3.28 6.38 3.35 6.20 3.39
2 1 7.31 3.12 7.23 3.18 7.09 3.25 6.94 3.31 6.86 3.35 6.71 3.41 6.56 3.45
7 6 9.27 2.86 9.18 2.92 9.00 2.98 8.82 3.04 8.73 3.07 8.55 3.13 8.37 3.16
10 8 9.64 2.93 9.55 2.99 9.37 3.04 9.20 3.10 9.11 3.13 8.94 3.18 8.76 3.21
15 12 9.87 2.98 9.78 3.04 9.61 3.09 9.43 3.15 9.34 3.18 9.16 3.23 8.98 3.26
20 15 10.06 2.92 9.97 2.98 9.77 3.04 9.58 3.09 9.48 3.12 9.28 3.18 9.09 3.21
24 18 10.22 2.86 10.11 2.92 9.90 2.98 9.69 3.04 9.59 3.08 9.37 3.14 9.16 3.17
Outdoor temperature
Indoor temperature
16°CDB
18°CDB
20°CDB
23°CDB
25°CDB
27°CDB
30°CDB
8-1. CAPACITY TABLE
8. APPENDING DATA
