Fujitsu AU*24LUAR - Page 93

08-02
MODEL : AU*30LUAS / AO*30LMAWL
MODEL : AUT30LUAS / AOT30LMAWL
COOLING
AFR 26
(°CDB) TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
-10 7.59 5.79 1.97 7.73 6.18 1.99 7.99 6.48 2.01 8.12 6.40 2.02 8.36 6.28 2.04 8.48 6.13 2.05 8.58 6.49 2.05
0 8.73 6.49 1.73 8.96 7.16 1.74 9.40 7.63 1.75 9.62 7.59 1.75 10.05 7.48 1.76 10.27 7.44 1.77 10.47 7.93 1.77
10 7.58 5.71 2.05 7.77 6.15 2.06 8.15 6.63 2.07 8.34 6.53 2.08 8.71 6.46 2.09 8.88 6.35 2.09 9.05 6.78 2.10
20 10.04 7.13 2.31 10.40 7.82 2.31 11.14 8.47 2.30 11.52 8.45 2.29 12.28 8.39 2.28 12.67 8.36 2.27 13.05 8.98 2.26
30 8.74 6.60 2.78 9.07 7.29 2.78 9.73 7.95 2.79 10.07 7.93 2.79 10.77 7.88 2.78 11.11 7.85 2.78 11.46 8.48 2.78
35 8.66 6.57 3.41 8.99 7.26 3.43 9.66 7.92 3.45 10.00 7.90 3.46 10.61 7.83 3.41 10.96 7.80 3.41 11.30 8.43 3.42
40 7.09 4.90 3.30 7.37 5.49 3.30 7.95 6.08 3.30 8.25 6.15 3.30 8.86 6.22 3.30 9.08 6.16 3.30 9.38 6.71 3.30
43 6.53 4.74 3.30 6.79 5.25 3.30 7.25 5.75 3.30 7.53 5.79 3.30 8.08 5.83 3.30 8.36 5.82 3.30 8.64 6.34 3.30
Indoor temperature
26°CDB 27°CDB 29°CDB
18°CWB 19°CWB
21°CDB 23°CDB
Outdoor temperature
15°CWB 16°CWB 21°CWB 22°CWB 23°CWB
32°CDB30°CDB
HEATING
AFR 26
(°CDB) (°CWB) TC PI TC PI TC PI TC PI TC PI TC PI TC PI
-10 -11 7.73 2.79 7.56 2.85 7.49 3.00 7.22 3.08 6.99 3.09 6.76 3.10 6.38 3.10
-4 -6 8.87 3.02 8.69 3.08 8.44 3.09 8.02 3.09 7.77 3.11 7.52 3.12 7.11 3.11
1 -1 10.21 3.10 9.95 3.11 9.58 3.09 9.11 3.09 8.83 3.10 8.54 3.12 8.04 3.11
7 6 11.77 3.37 11.50 3.37 11.20 3.37 10.57 3.37 10.22 3.37 9.79 3.37 9.20 3.37
12 10 13.83 3.37 13.35 3.37 13.12 3.37 12.35 3.37 11.92 3.37 11.48 3.37 10.77 3.37
18 13 13.32 3.13 13.15 3.22 12.95 3.30 12.61 3.41 12.30 3.48 11.92 3.55 11.34 3.68
24 17 12.77 3.02 12.62 3.10 12.45 3.18 11.95 3.18 11.56 3.19 11.21 3.21 10.52 3.22
23°CDB 25°CDB 27°CDB 30°CDB
Outdoor temperature
Indoor temperature
16°CDB 18°CDB 20°CDB
COOLING
HEATING
AFR 26.7
(°CDB) TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
-10
6.58 5.69 1.77 7.33 5.72 1.80 7.58 6.22 1.81 8.08 6.24 1.83 8.33 6.74 1.83 8.83 6.72 1.85 9.33 7.15 1.87
0
7.62 6.14 1.55 8.48 6.18 1.57 8.77 6.71 1.58 9.35 6.74 1.60 9.64 7.28 1.61 10.22 7.25 1.62 10.80 7.72 1.64
5
7.09 5.90 1.67 7.89 5.94 1.69 8.16 6.46 1.70 8.70 6.48 1.72 8.97 7.00 1.73 9.51 6.97 1.74 10.04 7.42 1.76
10
6.69 5.73 1.84 7.45 5.77 1.87 7.70 6.27 1.88 8.21 6.29 1.89 8.46 6.79 1.90 8.97 6.77 1.92 9.48 7.21 1.94
15
7.88 6.26 2.07 8.78 6.30 2.10 9.08 6.84 2.11 9.67 6.87 2.14 9.97 7.42 2.15 10.57 7.39 2.17 11.17 7.87 2.19
20
8.86 6.70 2.10 9.87 6.75 2.13 10.21 7.33 2.14 10.88 7.36 2.16 11.22 7.95 2.18 11.89 7.92 2.20 12.57 8.43 2.22
25
8.48 6.53 2.38 9.44 6.57 2.42 9.76 7.14 2.43 10.41 7.17 2.46 10.73 7.73 2.47 11.37 7.71 2.49 12.02 8.21 2.52
30
7.84 6.24 2.55 8.73 6.28 2.59 9.03 6.82 2.60 9.63 6.85 2.63 9.92 7.39 2.64 10.52 7.37 2.66 11.11 7.84 2.69
35
7.90 6.27 3.37 8.80 6.31 3.43 9.10 6.85 3.44 9.70 6.88 3.48 10.00 7.43 3.50 10.60 7.40 3.53 11.20 7.88 3.57
40
6.73 5.75 3.08 7.50 5.79 3.13 7.76 6.29 3.14 8.27 6.31 3.17 8.52 6.82 3.19 9.03 6.79 3.22 9.55 7.23 3.25
43
6.27 5.55 3.11 6.98 5.59 3.16 7.22 6.07 3.18 7.69 6.09 3.21 7.93 6.58 3.23 8.41 6.55 3.26 8.88 6.98 3.29
Outdoor temperature
16 °CWB 18 °CWB12 °CWB 15 °CWB 21 °CWB 23 °CWB
Indoor temperature
18 °CDB 21 °CDB 23 °CDB 25 °CDB 29 °CDB 32 °CDB
19 °CWB
27 °CDB
AFR
26.7
(°CDB) (°CWB)
TC PI TC PI TC PI TC PI TC PI
-10 -11
8.18 3.20 7.98 3.26 7.79 3.33 7.60 3.40 7.40 3.46
-5 -7
9.21 3.37 8.99 3.44 8.77 3.51 8.55 3.58 8.33 3.65
0 -2
10.32 3.42 10.07 3.49 9.83 3.56 9.58 3.63 9.34 3.70
5 3
11.34 3.44 11.07 3.51 10.80 3.58 10.53 3.65 10.26 3.73
7 6
11.76 3.36 11.48 3.43 11.20 3.50 10.92 3.57 10.64 3.64
10 8
12.19 3.38 11.90 3.45 11.61 3.52 11.32 3.59 11.03 3.66
15 10
12.49 3.37 12.20 3.44 11.90 3.51 11.60 3.58 11.30 3.65
20 15
12.35 3.00 12.06 3.07 11.76 3.13 11.47 3.19 11.18 3.26
24 18
12.87 2.97 12.56 3.03 12.26 3.10 11.95 3.16 11.64 3.22
Outdoor temperature
Indoor temperature
16°CDB 18°CDB 20°CDB 22°CDB 24°CDB
AFR: Air flow rate (m
3
/min)
TC : Total capacity (kW)
SHC: Sensible Heat capacity (kW)
PI : Power Input (kW)
AFR: Air flow rate (m
3
/min)
TC : Total capacity (kW)
SHC: Sensible Heat capacity (kW)
PI : Power Input (kW)
