CASSETTE TYPE AUTG09-12LVLB
3. Specifications
3-1. Models: AUTG09LVLB and AUTG12LVLB
Type
Cassette
Inverter heat pump
Model name AUTG09LVLB AUTG12LVLB
Power supply 240 V ~ 50 Hz
Available voltage range 198—264 V
Star rating index 10 star standard
Cooling 3.5 2.5
Heating 3.5 3.0
Capacity
Cooling
Rated
kW 2.60 3.50
Btu/h 8,870 11,900
Min.—Max.
kW 0.9 — 3.6 0.9 — 4.0
Btu/h 3,000 — 11,900 3,000 — 13,600
Heating
Rated
kW 3.50 4.00
Btu/h 11,900 13,600
Min.—Max.
kW 0.9 — 4.48 0.9 — 4.83
Btu/h 3,000 — 15,200 3,000 — 16,400
Input power
Cooling
Rated
kW
0.60 0.91
Max. 1.92 1.99
Heating
Rated 0.83 0.98
Max. 2.28 2.37
Fan
HIGH
W
18 23
MED 15 18
LOW 14 15
QUIET 12 13
Current
Cooling
Rated A
2.9 4.3
Heating 4.1 4.7
Power Factor
Cooling
%
86.2 88.2
Heating 88.0 86.9
EER Cooling
kW/kW
4.33 3.85
COP Heating 4.22 4.08
Moisture removal L/h (pints/h) 0.50 (0.88) 0.90 (1.58)
Maximum operating current *1
Cooling
A
9.3 9.4
Heating 10.8 10.9
Fan
Airflow rate
Cooling
HIGH
l/s (m
3
/h)
150 (540) 169 (610)
MED 136 (490) 147 (530)
LOW 122 (440) 131 (470)
QUIET 108 (390) 114 (410)
Heating
HIGH 150 (540) 167 (600)
MED 136 (490) 147 (530)
LOW 122 (440) 131 (470)
QUIET 108 (390) 114 (410)
Type × Q'ty Turbo fan × 1
Motor output W 54
Sound pressure level *2
Cooling
HIGH
dB (A)
33 37
MED 32 33
LOW 29 31
QUIET 28 28
Heating
HIGH 34 37
MED 32 33
LOW 29 31
QUIET 27 28
Heat exchanger type
Dimensions (H × W × D)
mm
210 × 1,310 × 13.3
210 × 1,250 × 13.3
Fin pitch 1.2
Rows × Stages 2 × 10
Pipe type Copper tube
Fin type Aluminum
Dimensions
(H × W × D)
Net
mm
245 × 570 × 570
Gross 265 × 730 × 625
Weight
Net
kg
15
Gross 18
Connection pipe
Size
Liquid
mm (in)
Ø 6.35 (Ø 1/4)
Gas Ø 9.52 (Ø 3/8)
Method Flare
Drain hose
Material PVC
Size mm VP25 [Ø 25 (I.D.), Ø 32 (O.D.)]
Operation range
Cooling
°C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Cassette grille
Material PS
Color
White
Approximate color of MUNSELL N 9.25/
Dimensions
(H × W × D)
Net
mm
49 × 700 × 700
Gross 120 × 765 × 755
Weight
Net
kg
2.6
Gross 4.5
Remote controller type Wireless (Wired [option])
