- 2 -
CASSETTE TYPE AUTG09-12LVLB
1. Product features
Implemented core technology provides easy-to-use product operations that realize a comfortable
space.
1-1. Model lineup
1-2. Features
• 2-stage turbo fan
High efficiency design by 2 stage structure
• Quiet quality
Optimization of wing form (laminar wing type) and wing number (7 blades each)
AUTG09LVLB
AUTG12LVLB
AOTG09LBCB
AOTG12LBCB
+
2 stage
Wind
velocity
Fast
Slow
Previous turbo fan
In the case of a
conventional fan, the air
outlet range was narrow
the motor side which
meant the velocity of air
passing through the heat
exchanger was uneven.
2-stage turbo fan
A evenly spread air distribution across
the heat exchanger is possible due
to the new 2 stage turbo fan which
streams.
1-stage
2-stage
Heat exchange
20%UP
Laminar wing
along the laminar wing
Quiet
Spin direction
Quiet
Adoption of laminar wing
