Fujitsu AUXG07KVLA Design & Technical Manual

• When function setting is "Forced stop" mode
– In the case of "Edge" input:
Function
setting /
Rotary SW on
External input and
output PCB
External input Input signal Command
46-02 60-00 / 1
External input and
output PCB
CN313
Off → On Forced stop
On → Off Normal
On
Off
Forced stop
Normal
Operation
Stop
Remote controller
On On
Indoor unit
On
CN313
– In the case of "Pulse" input:
Function
setting /
Rotary SW on
External input and
output PCB
External input Input signal Command
46-02 60-00 / 1
External input and
output PCB
CN313 Pulse Forced stop
CN314 Pulse Normal
On
Off
Operation
Stop
Remote controller
On
Off
Forced stop
Normal
CN313
CN314
On On On
Indoorunit
NOTES:
• When the forced stop is triggered, indoor unit stops and Operation/Stop operation by the re-
mote controller is restricted.
• When forced stop function is used with forming a remote controller group, connect the same
equipment to each indoor unit within the group.
- 111 -
11-2. Wall mounted type (Models: ASYG07KGTB, ASYG09KGTB, ASYG12KGTB,
ASYG14KGTB, ASYG07KETA, ASYG09KETA, ASYG12KETA, ASYG14KETA,
ASYG07KETA-B, ASYG09KETA-B, ASYG12KETA-B, and ASYG14KETA-B)
11. External input and output
