Fujitsu AUXG07KVLA Design & Technical Manual

Model: ASYG07KETA, ASYG07KETA-B
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04
0.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04
5.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04
10.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04
15.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04
20.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04
25.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04
30.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04
35.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04
40.0 1.54 0.68 1.74 0.78 1.84 0.90 1.97 1.01 2.10 1.10 2.17 1.26
46.0 1.12 0.36 1.27 0.41 1.34 0.48 1.43 0.54 1.53 0.59 1.58 0.67
Model: ASYG09KETA, ASYG09KETA-B
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.51 1.41 2.84 1.61 2.99 1.85 3.20 2.08 3.42 2.27 3.53 2.61
0.0 2.51 1.41 2.84 1.61 2.99 1.85 3.20 2.08 3.42 2.27 3.53 2.61
5.0 2.51 1.41 2.84 1.61 2.99 1.85 3.20 2.08 3.42 2.27 3.53 2.61
10.0 2.51 1.41 2.84 1.61 2.99 1.85 3.20 2.08 3.42 2.27 3.53 2.61
15.0 2.51 1.41 2.84 1.61 2.99 1.85 3.20 2.08 3.42 2.27 3.53 2.61
20.0 2.51 1.41 2.84 1.61 2.99 1.85 3.20 2.08 3.42 2.27 3.53 2.61
25.0 2.51 1.41 2.84 1.61 2.99 1.85 3.20 2.08 3.42 2.27 3.53 2.61
30.0 2.51 1.41 2.84 1.61 2.99 1.85 3.20 2.08 3.42 2.27 3.53 2.61
35.0 2.51 1.41 2.84 1.61 2.99 1.85 3.20 2.08 3.42 2.27 3.53 2.61
40.0 1.97 0.87 2.23 1.00 2.35 1.15 2.52 1.29 2.69 1.41 2.78 1.61
46.0 1.44 0.46 1.63 0.53 1.72 0.61 1.84 0.69 1.96 0.75 2.02 0.86
Model: ASYG12KETA, ASYG12KETA-B
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.87 1.61 3.24 1.84 3.42 2.12 3.66 2.38 3.91 2.60 4.03 2.98
0.0 2.87 1.61 3.24 1.84 3.42 2.12 3.66 2.38 3.91 2.60 4.03 2.98
5.0 2.87 1.61 3.24 1.84 3.42 2.12 3.66 2.38 3.91 2.60 4.03 2.98
10.0 2.87 1.61 3.24 1.84 3.42 2.12 3.66 2.38 3.91 2.60 4.03 2.98
15.0 2.87 1.61 3.24 1.84 3.42 2.12 3.66 2.38 3.91 2.60 4.03 2.98
20.0 2.87 1.61 3.24 1.84 3.42 2.12 3.66 2.38 3.91 2.60 4.03 2.98
25.0 2.87 1.61 3.24 1.84 3.42 2.12 3.66 2.38 3.91 2.60 4.03 2.98
30.0 2.87 1.61 3.24 1.84 3.42 2.12 3.66 2.38 3.91 2.60 4.03 2.98
35.0 2.87 1.61 3.24 1.84 3.42 2.12 3.66 2.38 3.91 2.60 4.03 2.98
40.0 2.26 1.00 2.55 1.14 2.69 1.31 2.88 1.47 3.08 1.61 3.17 1.85
46.0 1.65 0.53 1.86 0.61 1.96 0.70 2.10 0.78 2.25 0.86 2.31 0.98
Model: ASYG14KETA, ASYG14KETA-B
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.03 1.71 3.43 1.94 3.61 2.24 3.87 2.52 4.14 2.75 4.26 3.15
0.0 3.03 1.71 3.43 1.94 3.61 2.24 3.87 2.52 4.14 2.75 4.26 3.15
5.0 3.03 1.71 3.43 1.94 3.61 2.24 3.87 2.52 4.14 2.75 4.26 3.15
10.0 3.03 1.71 3.43 1.94 3.61 2.24 3.87 2.52 4.14 2.75 4.26 3.15
15.0 3.03 1.71 3.43 1.94 3.61 2.24 3.87 2.52 4.14 2.75 4.26 3.15
20.0 3.03 1.71 3.43 1.94 3.61 2.24 3.87 2.52 4.14 2.75 4.26 3.15
25.0 3.03 1.71 3.43 1.94 3.61 2.24 3.87 2.52 4.14 2.75 4.26 3.15
30.0 3.03 1.71 3.43 1.94 3.61 2.24 3.87 2.52 4.14 2.75 4.26 3.15
35.0 3.03 1.71 3.43 1.94 3.61 2.24 3.87 2.52 4.14 2.75 4.26 3.15
40.0 2.39 1.06 2.70 1.20 2.84 1.39 3.05 1.56 3.26 1.70 3.36 1.95
46.0 1.74 0.56 1.97 0.64 2.07 0.74 2.22 0.83 2.37 0.91 2.45 1.04
NOTES:
• TC: Total Capacity (kW), SHC: Sensible Heat Capacity (kW)
• Values mentioned in the table are based on the following conditions:
– Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
- 260 -
6-2. Cooling capacity 6. Capacity table
OUTDOOR UNIT AOYG14-18KBTA2 OUTDOOR UNIT AOYG14-18KBTA2
