Fujitsu AUXG07KVLA Design & Technical Manual


Floor type
Model: AGYG09KVCA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
-5.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
0.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
5.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
10.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
15.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
20.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
25.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
30.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
35.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
40.0 2.37 1.53 2.68 1.75 2.83 2.01 3.03 2.26 3.24 2.48 3.34 2.84
46.0 2.24 1.37 2.53 1.56 2.67 1.79 2.86 2.01 3.05 2.20 3.15 2.52
Model: AGYG12KVCA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.87 1.84 3.24 2.09 3.42 2.41 3.66 2.71 3.91 2.96 4.03 3.39
-5.0 2.87 1.84 3.24 2.09 3.42 2.41 3.66 2.71 3.91 2.96 4.03 3.39
0.0 2.87 1.84 3.24 2.09 3.42 2.41 3.66 2.71 3.91 2.96 4.03 3.39
5.0 2.87 1.84 3.24 2.09 3.42 2.41 3.66 2.71 3.91 2.96 4.03 3.39
10.0 2.87 1.84 3.24 2.09 3.42 2.41 3.66 2.71 3.91 2.96 4.03 3.39
15.0 2.87 1.84 3.24 2.09 3.42 2.41 3.66 2.71 3.91 2.96 4.03 3.39
20.0 2.87 1.84 3.24 2.09 3.42 2.41 3.66 2.71 3.91 2.96 4.03 3.39
25.0 2.87 1.84 3.24 2.09 3.42 2.41 3.66 2.71 3.91 2.96 4.03 3.39
30.0 2.87 1.84 3.24 2.09 3.42 2.41 3.66 2.71 3.91 2.96 4.03 3.39
35.0 2.87 1.84 3.24 2.09 3.42 2.41 3.66 2.71 3.91 2.96 4.03 3.39
40.0 2.72 1.64 3.07 1.87 3.23 2.16 3.46 2.42 3.70 2.65 3.82 3.04
46.0 2.56 1.46 2.89 1.67 3.05 1.92 3.27 2.16 3.49 2.36 3.60 2.70
Model: AGYG14KVCA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.03 1.89 3.43 2.15 3.61 2.48 3.87 2.79 4.14 3.05 4.26 3.49
-5.0 3.03 1.89 3.43 2.15 3.61 2.48 3.87 2.79 4.14 3.05 4.26 3.49
0.0 3.03 1.89 3.43 2.15 3.61 2.48 3.87 2.79 4.14 3.05 4.26 3.49
5.0 3.03 1.89 3.43 2.15 3.61 2.48 3.87 2.79 4.14 3.05 4.26 3.49
10.0 3.03 1.89 3.43 2.15 3.61 2.48 3.87 2.79 4.14 3.05 4.26 3.49
15.0 3.03 1.89 3.43 2.15 3.61 2.48 3.87 2.79 4.14 3.05 4.26 3.49
20.0 3.03 1.89 3.43 2.15 3.61 2.48 3.87 2.79 4.14 3.05 4.26 3.49
25.0 3.03 1.89 3.43 2.15 3.61 2.48 3.87 2.79 4.14 3.05 4.26 3.49
30.0 3.03 1.89 3.43 2.15 3.61 2.48 3.87 2.79 4.14 3.05 4.26 3.49
35.0 3.03 1.89 3.43 2.15 3.61 2.48 3.87 2.79 4.14 3.05 4.26 3.49
40.0 2.87 1.69 3.24 1.93 3.42 2.22 3.66 2.49 3.91 2.73 4.04 3.13
46.0 2.71 1.50 3.06 1.72 3.23 1.97 3.45 2.22 3.69 2.43 3.81 2.78
NOTES:
• TC: Total Capacity (kW), SHC: Sensible Heat Capacity (kW)
• Values mentioned in the table are based on the following conditions:
– Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
- 261 -
6-2. Cooling capacity 6. Capacity table
