43 2 stage turbo fan assy
Cabinet A sub assy
9375480011
42 Fan motor
Top plate assy
Motor wire holder
9602436019
41 Fan motor sub assy 9375719012
44 Shaft cap
Cabinet B sub assy
44
45
43
Turbo fan washer
9377807014
45 Washer cover 9377811011
Ref. Description Part number
2-1. Models: AUXG09KVLA, AUXG12KVLA, AUXG14KVLA, AUXG18KVLA, and AUXG22KVLA - (02-6) - 2. Indoor unit parts list
