Separate wall
Evaporator holder 2 row
Evaporator total assy (09, 12)
Evaporator total assy (14)
31 9377914101
31
9377914118
Evaporator total assy (18)31 9377914125
31 Evaporator total assy (07) 9377914156
32 Insulation box sub assy (22, 24) 9377764058
32 Insulation box sub assy
(07-18) 9377764065
Ref.
Description
Part number
32
31
31
Evaporator total assy
(22, 24) 9377914149
2-1. Models: AUXG09KVLA, AUXG12KVLA, AUXG14KVLA, AUXG18KVLA, and AUXG22KVLA - (02-5) - 2. Indoor unit parts list
