Brief descript ion of mainboard
Brief description of mainboar
d
Information about boards
Be sure to observe the following for boards with ESD :
• You must always discharge static build up (e .g. by touching a grounded object)
before working with the board.
• The equipment and tools you use must be free of static charge.
• Remove the power plug from th e mains supply before inserting or removing
boards.
• Always hold boards by their edges.
• Never touch connector pins or condu ctors on the board.
An overview of the features is provided in the data sheet.
Special features
You r mainboard is available in different configuration levels. Depending on the c on figuration,
your mainboard will be equipped with or provide support for certain features.
This manual describes the most important properties of this mainboard.
Additional information on mainboards is provided in the manual "Basic information on mainboard"
on the "U ser Documentation" or "OEM Mainboard" CD, or on the Inte rnet.
Interfaces and connectors
The location of the interf
aces and c onnectors of your mainboard is specified
at the beginning of the man
ual.
The components and conne ct
ors marked are not necessarily present on the mainboard.
External ports
The location of the extern
al connections of your mainboard is specified at the beginning of the manual.
PS/2 keyboard port, purple PS/2 mouse port, green
LAN port (RJ-45)
Microphone jack, pink
Audio input (Line in), light blue USB – Universal Serial Bus, black
Audio output (Line ou t),
light green
VGA, blue
Serial interface, turqu
oise
In accordance with the USB 2.0 speci fication, the external USB ports must
only be loaded with a maximum of 500 mA per USB port.
A26361-D2811-Z210-1-8N19, edition 1 English - 1
