Fujitsu D3633 User Manual

Internal connectors and slots
External connectors rear
USB 3.1
Gen 1
USB 3.1
Gen 2
DVI-D
Front panel
USB 2.0
DP 1.2
(Display
port)
Recovery inserted = The system starts
from USB stick and allows a BIOS recovery.
Details can be found in the BIOS manual.
1
2
HD-LED
Recovery
Reset
Power
On/Off
Power LED
USB 2.0
CPU
USB 3.1
Gen 2
SATA 2
PWR 1
PS/2
USB 2.0
4x
DP 2x
DVI-D / COM
LAN 2
FAN 1
LVDS Inv.
Buzzer
SPDIF
Frontpanel eDP Conn.
eDP Jump
PCH
Battery
Audio
SATA 3 SATA 0SATA 1
COM 2
LVDS
LVDS
Supply
GPIO
FAN 2
PWR 2
USB 3.1
Gen 2 (2x)
LAN 1
USB 3.1
Gen 1 (2x)
SLOT 1 (PCIe x16)
M.2 PCIe x4
USB 3.1
Gen 1
miniPCIe
D3633
Channel A, Slot 1
Channel B, Slot 1
Audio Front
Panel Connector
Intrusion
Fujitsu

Fujitsu D3633 Specifications

General

Brand	Fujitsu
Model	D3633
Category	Motherboard
Language	English
